RL78/G1H CHAPTER 18 RF TRANSCEIVER
R01UH0575EJ0120 Rev. 1.20 Page 595 of 920
Dec 22, 2016
Figure 18 - 36 Baseband Interrupt Source Register 1 (BBINTREQ1) Format
Address:
0037H
After reset: 00H R
Symbol76543210
BBINTREQ1 LVLFILINTREQ MODESWINTREQ ROVRINTREQ ADRSINTREQ RCVSTINTREQ RCV1INTREQ RCV0INTREQ RCVFININTREQ
LVLFILINTREQ Receive level filter interrupt source bit
0 No request
1 Request exists
MODESWINTREQ Mode switch receive completion interrupt source bit
0 No request
1 Request exists
ROVRINTREQ Receive overrun interrupt source bit
0 No request
1 Request exists
ADRSINTREQ Address filter interrupt source bit
0 No request
1 Request exists
RCVSTINTREQ Receive start interrupt source bit
0 No request
1 Request exists
RCV1INTREQ Bank 1 receive completion interrupt source bit
0 No request
1 Request exists
RCV0INTREQ Bank 0 receive completion interrupt source bit
0 No request
1 Request exists
RCVFININTREQ Frame receive completion interrupt source bit
0 No request
1 Request exists
