(38) Back off cycle register (BOFFPERIOD)
This register is used to set the back off cycle. Initial value: 0071H= 113 symbols (Set value: 1H = 1 symbol)
The BOFFPERIOD register consists of 16 bits and can be accessed (serial interface communication) in 8 bit
unit.
Reset signal generation sets this register to 0071H.
Figure 18 - 51 Back-off Cycle Register (BOFFPERIOD) Format
Address:
004BH, 004AH
After reset:
0071H
R/W
Symbol 15 14 13 12 11 10 9 8
BOFFPER
IOD
76543210
BOFFPERIOD
Back off cycle setting value
To Next Page
