RL78/G1H CHAPTER 18 RF TRANSCEIVER
R01UH0575EJ0120 Rev. 1.20 Page 635 of 920
Dec 22, 2016
(73) RF initial setting register 00 to 02 (RFINI00 to RFINI02)
Data read/write area with sub-address is implemented in RF block. These registers are used to set the area.
These registers consist of 24 bits.
-Data write
Write RF initial setting register 00 and RF initial setting register 01 continuously.
RF initial setting register 00 (bits 7 to 0): write data
RF initial setting register 01 (bit 7): 0
RF initial setting register 01 (bits 6 to 0): sub-address in RF
-Data read
Write RF initial setting register 00 and RF initial setting register 01 continuously.
RF initial setting register 00 (bits 7 to 0): 00H
RF initial setting register 01 (bit 7): 1
RF initial setting register 01 (bits 6 to 0): sub-address in RF
Read RF initial setting register 02 after writing RF initial setting register 00 and 01.
Caution Two bytes of RF initial setting register 00 and 01 must be written continuously (SEN signal
keeps low level).
RF initial setting register 00 to 02 are set via serial interface in 8-bit units.
RF initial setting register 00 and 01 are write only and the read values are undefined.
RF initial setting register 02 is read only and the initial value is undefined.
Figure 18 - 86 RF initial setting register 00 to 02 (RFINI00 to RFINI02) Format
Address:
00D8H
After reset: undefined
W
Symbol76543210
RFINI00 RFINI007 RFINI006 RFINI005 RFINI004 RFINI003 RFINI002 RFINI001 RFINI000
RFINI00 RFINI00 value
Address:
00D9H
After reset: undefined
W
Symbol76543210
RFINI01 RFINI017 RFINI016 RFINI015 RFINI014 RFINI013 RFINI012 RFINI011 RFINI010
RFINI01 RFINI01 value
Address:
00DAH
After reset: undefined
R
Symbol76543210
RFINI02 RFINI027 RFINI026 RFINI025 RFINI024 RFINI023 RFINI022 RFINI021 RFINI020
RFINI02 RFINI02 value
