RL78/G1H CHAPTER 18 RF TRANSCEIVER
R01UH0575EJ0120 Rev. 1.20 Page 639 of 920
Dec 22, 2016
(78) Receive timeout register (BBTIMEOUT)
This register is used to set the timeout time when the automatic reception with timeout mode is enabled.
This register consists of 12 bits.
BBTIMEOUT register is set via serial interface in 8-bit units.
Reset signal generation sets this register to 07D0H. (07D0H = 2 ms, 1H = 1 μs)
Figure 18 - 91 Receive Timeout Register (BBTIMEOUT) Format
Caution Be sure to clear bits 12 to 15 to “0”.
Address:
00EDH, 00ECH
After reset:
07D0H
R/W
Symbol 15 14 13 12 11 10 9 8
BBTIMEO
UT
0000
76543210
BBTIMEOUT Timeout time setting value
