Renesas RL78/G1H

RL78/G1H CHAPTER 18 RF TRANSCEIVER
R01UH0575EJ0120 Rev. 1.20 Page 638 of 920
Dec 22, 2016
(77) Extended address register 1 (BBEXTENDAD10 to BBEXTENDAD13)
This register is used to set the extended address of second address filter. It consists of 64 bits (16 bit timed
by 4) and is used to detect the match with a received extended address.
BBEXTENDAD10 to BBEXTENDAD13 registers are set via serial interface in 8-bit units.
Reset signal generation clears these registers to 0000H.
Figure 18 - 90 Extended Address Register 1 (BBEXTENDAD10 to BBEXTENDAD13) Format
Address:
00EBH, 00EAH
After reset:
0000H
R/W
Symbol 15 14 13 12 11 10 9 8
BBEXTEN
DAD13
76543210
BBEXTENDAD13 Extended address bits 63 to 48
Address:
00E9H, 00E8H
After reset:
0000H
R/W
Symbol 15 14 13 12 11 10 9 8
BBEXTEN
DAD12
76543210
BBEXTENDAD12 Extended address bits 47 to 32
Address:
00E7H, 00E6H
After reset:
0000H
R/W
Symbol 15 14 13 12 11 10 9 8
BBEXTEN
DAD11
76543210
BBEXTENDAD11 Extended address bits 31 to 16
Address:
00E5H, 00E4H
After reset:
0000H
R/W
Symbol 15 14 13 12 11 10 9 8
BBEXTEN
DAD10
76543210
BBEXTENDAD10 Extended address bits 15 to 0
