RL78/G1H CHAPTER 18 RF TRANSCEIVER
R01UH0575EJ0120 Rev. 1.20 Page 637 of 920
Dec 22, 2016
(75) PAN identifier register 1 (BBPANID1)
This register is used to set the PAN identifier of second address filter. It consists of 16 bits and is used to
detect the match with a received PAN identifier.
BBPANID1 register is set via serial interface in 8-bit units.
Reset signal generation sets this register to FFFFH.
Figure 18 - 88 PAN Identifier Register 1 (BBPANID1) Format
(76) Short address register 1 (BBSHORTAD1)
This register is used to set the short address of second address filter. It consists of 16 bits and is used to
detect the match with a received PAN identifier.
BBSHORTAD1 register is set via serial interface in 8-bit units.
Reset signal generation sets this register to FFFFH.
Figure 18 - 89 Short Address Register 1 (BBSHORTAD1) Format
Address:
00E1H, 00E0H
After reset: FFFFH R/W
Symbol 15 14 13 12 11 10 9 8
BBPANID1
76543210
BBPANID1 PAN identifier
Address:
00E3H, 00E2H
After reset:
FFFFH
R/W
Symbol 15 14 13 12 11 10 9 8
BBSHORT
AD1
76543210
BBSHORTAD1
Short address
