Renesas RL78/G1H

RL78/G1H CHAPTER 18 RF TRANSCEIVER
R01UH0575EJ0120 Rev. 1.20 Page 644 of 920
Dec 22, 2016
(83) SFD setting register 2 (BBSFD2)
This register is used to set the SFD value for FEC enabled frame transmission/reception when MRFSKSFD
bit is 0.
Set the following values for each modulation.
2FSK/2GFSK: 000072F6H
4FSK/4GFSK: BFAEFFBEH
The BBSFD2 register consists of 32 bits. Reset signal generation sets this register to undefined.
BBSFD2 register is set via serial interface in 8-bit units.
Figure 18 - 96 SFD Setting Register 2 (BBSFD2) Format
Address: 0103H-0100H After reset: XXXXXXXXH R/W
Symbol 31 30 29 28 27 26 25 24
BBSFD2 SFD231 SFD230 SFD229 SFD228 SFD227 SFD226 SFD225 SFD224
23 22 24 20 19 18 17 16
SFD223 SFD222 SFD221 SFD220 SFD219 SFD218 SFD217 SFD216
15 14 13 12 11 10 9 8
SFD215 SFD214 SFD213 SFD212 SFD211 SFD210 SFD209 SFD208
76543210
SFD207 SFD206 SFD205 SFD204 SFD203 SFD202 SFD201 SFD200
SFD231-SFD200
SFD2 value
