(b) Zero flag (Z)
When the operation result is zero or equal, this flag is set (1). It is reset (0) in all other cases.
(c) Register bank select flags (RBS0, RBS1)
These are 2-bit flags to select one of the four register banks.
In these flags, the 2-bit information that indicates the register bank selected by SEL RBn instruction
execution is stored.
(d) Auxiliary carry flag (AC)
If the operation result has a carry from bit 3 or a borrow at bit 3, this flag is set (1). It is reset (0) in all other
cases.
(e) In-service priority flags (ISP1, ISP0)
This flag manages the priority of acknowledgeable maskable vectored interrupts. Vectored interrupt
requests specified lower than the value of ISP0 and ISP1 flags by the priority specification flag registers
(PRn0L, PRn0H, PRn1L, PRn1H, PRn2L, PRn2H) (see 19.3.3) can not be acknowledged. Actual
vectored interrupt requests acknowledgment is controlled by the interrupt enable flag (IE).
Remark n = 0, 1
(f) Carry flag (CY)
This flag stores overflow and underflow upon add/subtract instruction execution. It stores the shift-out
value upon rotate instruction execution and functions as a bit accumulator during bit operation instruction
execution.
(3) Stack pointer (SP)
This is a 16-bit register to hold the start address of the memory stack area. Only the internal RAM area can
be set as the stack area.
Figure 4 - 8 Format of Stack Pointer
15 0
SP SP15 SP14 SP13 SP12 SP11 SP10 SP9 SP8 SP7 SP6 SP5 SP4 SP3 SP2 SP1 0
