RL78/G1H CHAPTER 18 RF TRANSCEIVER
R01UH0575EJ0120 Rev. 1.20 Page 685 of 920
Dec 22, 2016
Table 18 - 34 RF Frequency Set (Frequency band identifier = 5, Mode = 006)
RF frequency set Lower limit RF frequency [MHz] Upper limit RF frequency [MHz] 0095H address Bit [7:0]
1 896.0000 896.0625 28H
2 896.0750 896.7250 8H
3 896.7375 896.8625 28H
4 896.8750 897.9250 8H
5 897.9375 897.9500 28H
6 897.9625 898.0625 48H
7 898.0750 899.1250 8H
8 899.1375 899.2625 28H
9 899.2750 899.9250 8H
10 899.9375 900.0375 28H
11 900.0500 900.0625 48H
12 900.0750 900.7250 8H
13 900.7375 900.8375 28H
14 900.8500 901.0000 8H
Table 18 - 35 RF Frequency Set (Frequency band identifier = 6, Mode = 007)
RF frequency set Lower limit RF frequency [MHz] Upper limit RF frequency [MHz] 0095H address Bit [7:0]
1 901.0000 901.9750 8H
2 901.9875 902.0000 28H
Table 18 - 36 RF Frequency Set (Frequency band identifier = 6, Mode = 008)
RF frequency set Lower limit RF frequency [MHz] Upper limit RF frequency [MHz] 0095H address Bit [7:0]
1 901.0000 901.9500 8H
2 901.9625 902.0000 28H
Table 18 - 37 RF Frequency Set (Frequency band identifier = 6, Mode = 009)
RF frequency set Lower limit RF frequency [MHz] Upper limit RF frequency [MHz] 0095H address Bit [7:0]
1 901.0000 901.9250 8H
2 901.9375 902.0000 28H
