RL78/G1H CHAPTER 18 RF TRANSCEIVER
R01UH0575EJ0120 Rev. 1.20 Page 684 of 920
Dec 22, 2016
Table 18 - 32 RF Frequency Set (Frequency band identifier = 5, Mode = 004)
RF frequency set Lower limit RF frequency [MHz] Upper limit RF frequency [MHz] 0095H address Bit [7:0]
1 896.0000 896.0125 28H
2 896.0250 896.1750 8H
3 896.1875 896.2125 28H
4 896.2250 897.9750 8H
5 897.9875 898.0125 28H
6 898.0250 899.7750 8H
7 899.7875 899.8125 28H
8 899.8250 899.9750 8H
9 899.9875 900.0125 28H
10 900.0250 900.1750 8H
11 900.1875 900.2125 28H
12 900.2250 901.0000 8H
Table 18 - 33 RF Frequency Set (Frequency band identifier = 5, Mode = 005)
RF frequency set Lower limit RF frequency [MHz] Upper limit RF frequency [MHz] 0095H address Bit [7:0]
1 896.0000 896.0375 28H
2 896.0500 896.3500 8H
3 896.3625 896.4375 28H
4 896.4500 897.9500 8H
5 897.9625 898.0375 28H
6 898.0500 899.5500 8H
7 899.5625 899.6375 28H
8 899.6500 899.9500 8H
9 899.9625 900.0375 28H
10 900.0500 900.3500 8H
11 900.3625 900.4375 28H
12 900.4500 901.0000 8H
To Next Page
