RL78/G1H CHAPTER 18 RF TRANSCEIVER
R01UH0575EJ0120 Rev. 1.20 Page 683 of 920
Dec 22, 2016
Table 18 - 29 RF Frequency Set (Frequency band identifier = 4, Mode = 001)
RF frequency set Lower limit RF frequency [MHz] Upper limit RF frequency [MHz] 0095H address Bit [7:0]
1 863.0000 863.5875 8H
2 863.6000 864.4000 Prohibited
3 864.4125 865.8500 8H
4 865.8625 866.1375 28H
5 866.1500 867.8500 8H
6 867.8625 868.1375 28H
7 868.1500 869.8500 8H
8 869.8625 870.0000 28H
Table 18 - 30 RF Frequency Set (Frequency band identifier = 4, Mode = 002)
RF frequency set Lower limit RF frequency [MHz] Upper limit RF frequency [MHz] 0095H address Bit [7:0]
1 863.0000 863.5875 8H
2 863.6000 864.4000 Prohibited
3 864.4125 865.7125 8H
4 865.7250 865.9750 48H
5 865.9875 866.2750 28H
6 866.2875 867.7125 8H
7 867.7250 867.9750 48H
8 867.9875 868.2750 28H
9 868.2875 869.7125 8H
10 869.7250 870.0000 28H
Table 18 - 31 RF Frequency Set (Frequency band identifier = 4, Mode = 003)
RF frequency set Lower limit RF frequency [MHz] Upper limit RF frequency [MHz] 0095H address Bit [7:0]
1 863.0000 863.5875 8H
2 863.6000 864.4000 Prohibited
3 864.4125 865.7500 8H
4 865.7625 865.9375 48H
5 865.9500 866.2375 28H
6 866.2500 867.7500 8H
7 867.7625 867.9375 48H
8 867.9500 868.2375 28H
9 868.2500 869.7500 8H
10 869.7625 870.0000 28H
