RL78/G1H CHAPTER 18 RF TRANSCEIVER
R01UH0575EJ0120 Rev. 1.20 Page 689 of 920
Dec 22, 2016
Table 18 - 41 RF Frequency Set (Frequency band identifier = 8, Mode = 013)
RF frequency set Lower limit RF frequency [MHz] Upper limit RF frequency [MHz] 0095H address Bit [7:0]
1 917.0000 917.8500 8H
2 917.8625 918.1375 28H
3 918.1500 919.8500 8H
4 919.8625 920.1375 28H
5 920.1500 921.8500 8H
6 921.8625 922.1375 28H
7 922.1500 923.5000 8H
Table 18 - 42 RF Frequency Set (Frequency band identifier = 8, Mode = 014)
RF frequency set Lower limit RF frequency [MHz] Upper limit RF frequency [MHz] 0095H address Bit [7:0]
1 917.0000 917.7250 8H
2 917.7375 918.2625 28H
3 918.2750 919.7250 8H
4 919.7375 920.2625 28H
5 920.2750 921.7250 8H
6 921.7375 922.2625 28H
7 922.2750 923.5000 8H
Table 18 - 43 RF Frequency Set (Frequency band identifier = 8, Mode = 015)
RF frequency set Lower limit RF frequency [MHz] Upper limit RF frequency [MHz] 0095H address Bit [7:0]
1 917.0000 917.6375 8H
2 917.6500 917.7250 48H
3 917.7375 918.3500 28H
4 918.3625 919.6375 8H
5 919.6500 919.7250 48H
6 919.7375 920.3500 28H
7 920.3625 921.6375 8H
8 921.6500 922.3500 28H
9 922.3625 923.5000 8H
Table 18 - 44 RF Frequency Set (Frequency band identifier = 8, Mode = 016)
RF frequency set Lower limit RF frequency [MHz] Upper limit RF frequency [MHz] 0095H address Bit [7:0]
1 920.0000 920.1375 28H
2 920.1500 921.8500 8H
3 921.8625 922.1375 28H
4 922.1500 923.8500 8H
5 923.8625 924.1375 28H
6 924.1500 925.8500 8H
7 925.8625 926.1375 28H
8 926.1500 927.8500 8H
9 927.8625 928.0000 28H
