RL78/G1H CHAPTER 18 RF TRANSCEIVER
R01UH0575EJ0120 Rev. 1.20 Page 690 of 920
Dec 22, 2016
Table 18 - 45 RF Frequency Set (Frequency band identifier = 9, Mode = 000)
RF frequency set Lower limit RF frequency [MHz] Upper limit RF frequency [MHz] 0095H address Bit [7:0]
1 920.0000 920.2750 28H
2 920.2875 921.7125 8H
3 921.7250 922.2750 28H
4 922.2875 923.7125 8H
5 923.7250 924.2750 28H
6 924.2875 925.7125 8H
7 925.7250 926.2750 28H
8 926.2875 927.7125 8H
9 927.7250 928.0000 28H
Table 18 - 46 RF Frequency Set (Frequency band identifier = 9, Mode = 017)
RF frequency set Lower limit RF frequency [MHz] Upper limit RF frequency [MHz] 0095H address Bit [7:0]
1 920.0000 920.5375 28H
2 920.5500 921.4500 8H
3 921.4625 921.6125 48H
4 921.6250 922.5250 28H
5 922.5375 923.4500 8H
6 923.4625 923.6125 48H
7 923.6250 924.5250 28H
8 924.5375 924.5375 48H
9 924.5500 925.4500 8H
10 925.4625 926.2125 28H
11 926.2250 926.2500 68H
12 926.2625 926.5375 48H
13 926.5500 927.4500 8H
14 927.4625 928.0000 28H
