Renesas RL78/G1H

RL78/G1H CHAPTER 18 RF TRANSCEIVER
R01UH0575EJ0120 Rev. 1.20 Page 691 of 920
Dec 22, 2016
Table 18 - 47 RF Frequency Set (Frequency band identifier = 9, Mode = 018)
RF frequency set Lower limit RF frequency [MHz] Upper limit RF frequency [MHz] 0095H address Bit [7:0]
1 920.0000 920.4750 28H
2 920.4875 921.5125 8H
3 921.5250 921.5500 48H
4 921.5625 922.4750 28H
5 922.4875 923.5125 8H
6 923.5250 923.5500 48H
7 923.5625 924.4750 28H
8 924.4875 925.5125 8H
9 925.5250 926.2750 28H
10 926.2875 926.4750 48H
11 926.4875 927.5125 8H
12 927.5250 928.0000 28H
Table 18 - 48 RF Frequency Set (Frequency band identifier = Other, Mode = 019)
RF frequency set Lower limit RF frequency [MHz] Upper limit RF frequency [MHz] 0095H address Bit [7:0]
1 920.0000 920.5125 28H
2 920.5250 921.4750 8H
3 921.4875 921.5875 48H
4 921.6000 922.5125 28H
5 922.5250 923.4750 8H
6 923.4875 923.5875 48H
7 923.6000 924.5125 28H
8 924.5250 925.4750 8H
9 925.4875 926.2375 28H
10 926.2500 926.5125 48H
11 926.5250 927.4750 8H
12 927.4875 928.0000 28H
