Renesas RL78/G1H

RL78/G1H CHAPTER 18 RF TRANSCEIVER
R01UH0575EJ0120 Rev. 1.20 Page 698 of 920
Dec 22, 2016
Table 18 - 55 Settings Required for Each Data Rate (4/9)
Frequency
band
identifier
PHY Mode
Data
rate
(kbps)
Address (H)
0423 0454 0456 0474 047C 047D 047F 0480 0483 0486 0487
4 863 MHz
(Europe)
001 50 01 28 02 A6 1B 0F 34 00 3E 55 05
002 100 01 28 02 A9 1B 0F 34 20 3F 00 00
003 200 09 28 02 A6 1B 0F 35 00 3F 33 03
5 896 MHz
(US)
004 10 09 28 02 A6 1B 0F 34 00 09 02 00
005 20 09 28 02 A6 1A 0F 34 00 03 32 00
006 40 09 28 02 A6 1A 0F 34 00 03 32 00
6 901 MHz
(US)
007 10 09 28 02 A6 1B 0F 34 00 09 02 00
008 20 09 28 02 A6 1A 0F 34 00 03 32 00
009 40 09 28 02 A6 1A 0F 34 00 03 32 00
7 915 MHz
(US)
010 50 01 28 02 A6 1B 0F 34 00 3B 55 05
011 150 09 28 02 A6 1B 0F 34 01 09 00 00
012 200 09 28 02 A6 1B 0F 34 00 09 00 00
8 917 MHz
(Korea)
013 50 01 28 02 A6 1B 0F 34 00 3F 55 05
014 150 09 28 02 A6 1B 0F 34 01 09 00 00
015 200 09 28 02 A6 1B 0F 34 00 09 00 00
9 920 MHz
(Japan)
016 50 01 28 02 A6 1B 0F 34 00 3C 55 05
000 100 01 2E 06 A6 1B 0F 34 20 3D 00 00
017 200 01 28 02 A6 1B 0F 34 01 3C 00 00
018 400 09 28 02 A7 1B 0F 34 01 3C 00 00
Other 019 300 09 28 02 A7 19 0D 33 02 19 00 00
020 100 09 28 02 A7 1B 0F 34 00 3D 00 00
021 300 09 28 02 A7 19 0D 33 06 19 00 00
