Table 18 - 56 Settings Required for Each Data Rate (5/9)
Frequency
band
identifier
PHY Mode
Data
rate
(kbps)
Address (H)
048D 048F 0491 0492 0493 0494 0581 0582 058F 059F 05A0
4 863 MHz
(Europe)
001 50 46 66 20 55 20 55 12 26 FF FF 3F
002 100 57 55 20 55 20 55 15 1C 32 56 03
003 200 46 66 30 55 30 55 10 24 FF FF 3F
5 896 MHz
(US)
004 10 46 66 20 55 20 55 05 30 FF FF 3F
005 20 46 55 20 55 20 55 00 30 FF FF 3F
006 40 46 55 20 55 20 55 1C 2B FF FF 3F
6 901 MHz
(US)
007 10 46 66 20 55 20 55 05 30 FF FF 3F
008 20 46 55 20 55 20 55 00 30 FF FF 3F
009 40 46 55 20 55 20 55 1C 2B FF FF 3F
7 915 MHz
(US)
010 50 46 66 20 55 20 55 12 26 FF FF 3F
011 150 57 55 20 55 20 55 12 26 FF FF 3F
012 200 57 55 20 55 20 55 16 2C FF FF 3F
8 917 MHz
(Korea)
013 50 46 66 20 55 20 55 12 26 FF FF 3F
014 150 57 55 20 55 20 55 12 26 FF FF 3F
015 200 57 55 20 55 20 55 16 2C FF FF 3F
9 920 MHz
(Japan)
016 50 46 66 20 55 20 55 12 26 FF FF 3F
000 100 57 55 20 55 20 55 15 1C 32 56 03
017 200 57 55 20 55 20 55 13 18 FF FF 3F
018 400 46 66 30 50 30 50 11 25 FF FF 3F
Other 019 300 46 55 20 54 20 54 15 21 FF FF 3F
020 100 46 55 20 54 20 54 17 33 FF FF 3F
021 300 46 55 20 54 20 54 15 21 FF FF 3F
