RL78/G1H CHAPTER 21 RESET FUNCTION

R01UH0575EJ0120 Rev. 1.20 Page 747 of 920

Dec 22, 2016

Figure 21 - 1 Block Diagram of Reset Function

Caution An LVD circuit internal reset does not reset the LVD circuit.

Remark 1. LVIM: Voltage detection register

Remark 2. LVIS: Voltage detection level register

Internal bus

Reset control flag register (RESF)

Watchdog timer reset signal

Reset signal

TRAP WDTRF RPERF IAWRF LVIRF

Set

Clear

Set Set SetSet

Clear Clear Clear Clear

Reset signal to LVIM/LVIS register

Reset signal by execution of illegal instruction

Reset signal by RAM parity error

Reset signal by illegal-memory access

RESF register read signal

RESET

Power-on reset circuit reset signal

Voltage detector reset signal
