RL78/G1H CHAPTER 21 RESET FUNCTION

R01UH0575EJ0120 Rev. 1.20 Page 754 of 920

Dec 22, 2016

Figure 21 - 5 Procedure for Checking Reset Source

Caution The flow shown above is an example of procedure for checking.

Yes

After reset acceptance

Internal reset request by the

watchdog timer generated

Internal reset request

by the voltage detector generated

Power-on-reset/

external reset generated

WDTRF of RESF

LVIRF of RESF

Yes

Internal reset request by the

RAM parity error generated

RPERF of RESF

Yes

Internal reset request by the

illegal memory access generated

IAWRF of RESF

Yes

Internal reset request by the

execution of the illegal instruction

generated

TRAP of RESF

Yes

Read RESF register

Read the RESF register (clear the RESF register) and

store the value of the RESF register in any RAM.
