RL78/G1H CHAPTER 4 CPU ARCHITECTURE

R01UH0575EJ0120 Rev. 1.20 Page 62 of 920

Dec 22, 2016

Table 4 - 12 Extended Special Function Register (2nd SFR) List (3/7)

Address

Extended Special Function Register

(2nd SFR) Name

Symbol R/W

Manipulable Bit Range

After Reset

1-bit 8-bit 16-bit

F0122H Serial channel start register 0 SS0L SS0 R/W

√√√0000H

F0123H — — —

F0124H Serial channel stop register 0 ST0L ST0 R/W

√√√0000H

F0125H — — —

F0126H Serial clock select register 0 SPS0L SPS0 R/W —

√√0000H

F0127H — — —

F0128H Serial output register 0 SO0 R/W — —

√ 0F0FH

F0129H

F012AH Serial output enable register 0 SOE0L SOE0 R/W

√√√0000H

F012BH — — —

F0134H Serial output level register 0 SOL0L SOL0 R/W —

√√0000H

F0135H — — —

F0140H Serial status register 10 SSR10L SSR10 R —

√√0000H

F0141H — — —

F0142H Serial status register 11 SSR11L SSR11 R —

√√0000H

F0143H — — —

F0144H Serial status register 12 SSR12L SSR12 R —

√√0000H

F0145H — — —

F0146H Serial status register 13 SSR13L SSR13 R —

√√0000H

F0147H — — —

F0148H Serial flag clear trigger register 10 SIR10L SIR10 R/W —

√√0000H

F0149H — — —

F014AH Serial flag clear trigger register 11 SIR11L SIR11 R/W —

√√0000H

F014BH — — —

F014CH Serial flag clear trigger register 12 SIR12L SIR12 R/W —

√√0000H

F014DH — — —

F014EH Serial flag clear trigger register 13 SIR13L SIR13 R/W —

√√0000H

F014FH — — —

F0150H Serial mode register 10 SMR10 R/W — —

√ 0020H

F0151H

F0152H Serial mode register 11 SMR11 R/W — —

√ 0020H

F0153H

F0154H Serial mode register 12 SMR12 R/W — —

√ 0020H

F0155H

F0156H Serial mode register 13 SMR13 R/W — —

√ 0020H

F0157H

F0158H Serial communication operation

setting register 10

SCR10 R/W — —

√ 0087H

F0159H

F015AH Serial communication operation

setting register 11

SCR11 R/W — —

√ 0087H

F015BH
