RL78/G1H CHAPTER 31 ELECTRICAL SPECIFICATIONS

R01UH0575EJ0120 Rev. 1.20 Page 874 of 920

Dec 22, 2016

Interrupt Request Input Timing

RESET

Input Timing

INTP0, INTP4,

INTP6, INTP7,

INTP9 to INTP11

tINTL tINTH

tRSL

RESET
