RL78/G1H CHAPTER 5 PORT FUNCTIONS

R01UH0575EJ0120 Rev. 1.20 Page 74 of 920

Dec 22, 2016

Table 5 - 4 PMxx, Pxx, PUxx, PIMxx, POMxx, PMCxx registers and the bits (1/2)

Port

Bit name

PMxx

Pxx

PUxx

PIMxx

POMxx

PMCxx

Port 0 2 PM02 P02 PU02 — POM02 PMC02

3 PM03 P03 PU03 PIM03 POM03 PMC03

4 PM04 P04 PU04 PIM04 POM04 —

Port 1 0 PM10 P10 PU10 — — —

1 PM11 P11 PU11 — — —

2PM12 P12 PU12 — — —

3PM13 P13 PU13 — — —

4PM14 P14 PU14 — — —

5PM15 P15 PU15 — — —

6PM16 P16 PU16 — — —

Port 2 0 PM20 P20 — — — —

1PM21 P21 — — — —

2PM22 P22 — — — —

Port 3 0 PM30 P30 PU30 — — —

1PM31 P31 PU31 — — —

Port 4 0 PM40 P40 PU40 — — —

Port 6 0 PM60 P60 — — — —

1PM61 P61 — — — —

2PM62 P62 — — — —

3PM63 P63 — — — —

Port 7 0 PM70 P70 PU70 — — —

1 PM71 P71 PU71 — POM71 —

2PM72 P72 PU72 — — —

5PM75 P75 PU75 — — —

6PM76 P76 PU76 — — —

7PM77 P77 PU77 — — —

Port 8 0 PM80 P80 PU80 PIM80 POM80 —

1 PM81 P81 PU81 PIM81 POM81 —

2 PM82 P82 PU82 — POM82 —

Port 10 0 PM100 P100 PU100 — — PMC100

Port 12 0 PM120 P120 PU120 — — PMC120

1— P121 — — — —

2— P122 — — — —

3— P123 — — — —

4— P124 — — — —

Port 13 0 — P130 — — — —

7— P137 — — — —
