26 July 2002 SERVICE PROGRAM MODE
5-19
Service
Tables
2
Mode No.
(Class 1, 2, and 3)
Function / [ Setting ]
2 Image Coverage–1 Specifies standard average coverage condition 1.
[50 ~ 800 / 300 / 10 units/step]
OPC lubrication is executed under the following
conditions.
• After the previous OPC lubrication, the number of
output pages reaches the value specified with SP2-
944-4.
• The average coverage of the outputs after the
previous OPC lubrication exceeds standard average
coverage condition 1.
3 Image Coverage–2 Specifies standard average coverage condition 2.
[50 ~ 800 / 200 / 10 units/step]
OPC lubrication is executed under the following
conditions.
• After the previous OPC lubrication, the number of
output pages reaches the value specified with SP2-
944-5.
• The average coverage of the outputs after the
previous OPC lubrication exceeds standard average
coverage condition 2.
4 Sheets–1
[10 ~ 80 / 20 / 1 sheet/step]
944
5 Sheets–2
[10 ~ 80 / 40 / 1 sheet/step]
Start Registration Adjustment
1
Start Registration
Adjustment 1–K
Color registration adjustment: Adjusts the start timing of
imaging for each color.
[–3 ~ 3 / 0 / 1 line/step] DFU
2 lines = 0.047566 ms (about 85 µm)
• +: Delays the start timing.
• –: Advances the start timing.
• The start timing is adjusted only in plain paper mode,
and when one of the following conditions is satisfied:
1) Between the two images on the transfer belt (when
two images are developed on the OPC at the
same time (
☛
6.2))
2) B4 SEF or larger (multi-print job)
2
Start Registration
Adjustment 1–M
[–3 ~ 3 / –1 / 1 line/step]
3
Start Registration
Adjustment 1–C
[–3 ~ 3 / 0 / 1 line/step]
4
Start Registration
Adjustment 1–Y
[–3 ~ 3 / 0 / 1 line/step]
5
Start Registration
Adjustment 2–K
[–3 ~ 3 / 0 / 1 line/step]
6
Start Registration
Adjustment 2–M
[–3 ~ 3 / –1 / 1 line/step]
7
Start Registration
Adjustment 2–C
[–3 ~ 3 / 0 / 1 line/step]
950
8
Start Registration
Adjustment 2–Y
[–3 ~ 3 / 0 / 1 line/step]
To Next Page
