Sel 751A - Page 162

Sel 751A
640 pages
Print Icon
To Next Page IconTo Next Page
To Next Page IconTo Next Page
To Previous Page IconTo Previous Page
To Previous Page IconTo Previous Page
Loading...
4.70
SEL-751A Relay Instruction Manual Date Code 20100129
Protection and Logic Functions
Reclose Logic
EXAMPLE 4.11 Factory Settings Example
The skip shot function is not enabled in the factory settings:
79SKP := 0 (numeral 0)
The stall open interval timing factory setting is:
79STL := TRIP
After successful reclose initiation, open interval timing does not start
as long as the trip condition is present (Relay Word bit TRIP = logical
1). As discussed previously, if an open interval time has not yet started
timing (79STL = logical 1 still), the 79SKP setting is still processed.
Once the trip condition goes away (Relay Word bit TRIP = logical 0),
open interval timing can proceed.
EXAMPLE 4.12 Additional Settings Example 1
With skip shot setting:
79SKP := 50P2P AND SH0
if shot = 0 (Relay Word bit SH0 = logical 1) and phase current is above
the phase instantaneous overcurrent element 50P2 threshold (Relay
Word bit 50P2P = logical 1), at the instant of successful reclose
initiation, the shot counter is incremented from shot = 0 to shot = 1.
Then, open interval 1 time (setting 79OI1) is skipped, and the relay
times on the open interval 2 time (setting 79OI2) instead.
In Tab le 4.2 9, note that the open interval 1 time (setting 79OI1) is a
short time, while the following open interval 2 time (setting 79OI2) is
significantly longer. For a high magnitude fault (greater than the
phase instantaneous overcurrent element 50P2 threshold), open
interval 1 time is skipped, and open interval timing proceeds on the
following open interval 2 time.
Once the shot is incremented to shot = 1, Relay Word bit SH0 = logical
0 and then setting 79SKP = logical 0, regardless of Relay Word bit
50P2P.
EXAMPLE 4.13 Additional Settings Example 2
If the SEL-751A Relay is used on a feeder with a line-side independent
power producer (cogenerator), the utility should not reclose into a
line still energized by an islanded generator. To monitor line voltage
and block reclosing, connect a line-side single-phase potential
transformer to channel VS on the SEL-751A as shown in Figure 4.36.
Table 4.29 Open Interval Time Example Settings
Shot
Corresponding
Relay Word Bit
Corresponding
Open Interval
Open Interval Time
Example Setting
(seconds
)
0 SH0 79OI1 0.50
1 SH1 79OI2 10
