9.10
SEL-751A Relay Instruction Manual Date Code 20100129
Analyzing Events
Event Reporting
=>>EVE <Enter>
SEL-751A Date: 06/05/2008 Time: 13:40:26.270
FEEDER RELAY
Serial Number=000000000000000
FID=SEL-751A-X215-V0-Z003002-D20080530 CID=0E1E
55555 55 8 O
11111 00 1 I u
A N n t
Currents (A Pri) Voltages (V Pri) B Q 1 13
IA IB IC IN IG VA VB VC VS VDC CPNGQ PG 2 2
[1]
-1739 467 1277 -0.0 4.2 -7429 -3317 10679 -7178 48 33... F. . . .3
449 -1735 1256 0.0 -30.0 7994 -10399 2259 8071 48 33... F. . . .3
1741 -468 -1279 0.0 -6.0 7421 3323 -10681 7173 48 33... F. . . .3
-454 1736 -1258 0.0 24.0 -7999 10395 -2255 -8080 48 33... F. . . .3
[2]
-1742 466 1278 -0.0 1.8 -7418 -3332 10679 -7171 48 33... F. . . .3
454 -1737 1258 -0.0 -25.2 7999 -10397 2246 8084 48 33... F. . . .3
1738 -465 -1283 0.0 -10.2 7412 3334 -10685 7162 48 33... F. . . .3
-456 1736 -1259 0.0 20.4 -8006 10391 -2243 -8087 48 33... F. . . .3
[3]
-1737 461 1283 0.0 7.2 -7409 -3341 10685 -7160 48 33... F. . . .3
455 -1737 1258 -0.0 -24.0 8010 -10393 2236 8089 48 33... F. . . .3
1735 -460 -1284 -0.0 -9.6 7402 3346 -10688 7153 48 33... F. . . .3
-456 1736 -1259 0.0 20.4 -8015 10388 -2232 -8095 48 33... F. . . .3
[4]
-1738 460 1282 0.0 3.6 -7402 -3353 10687 -7151 48 33... F. . . .3
457 -1737 1255 -0.0 -25.2 8015 -10388 2225 8096 48 33... F. . . .3
1737 -463 -1286 -0.0 -12.0 7396 3357 -10690 7146 48 33... F. . . .3
-459 1736 -1257 0.0 19.8 -8021 10384 -2219 -8102 48 33... F. . . .3
[5]
-1737 459 1285 -0.0 6.6 -7393 -3366 10690 -7142 48 33... F. . . .3
497 -1736 1255 -0.0 15.6 8024 -10384 2212 8104 48*33... F. . . .3
1363 -460 -1287 0.0 -384 7385 3368 -10692 7137 48 33.3. F. . . .3
-346 1738 -1256 0.0 136 -8030 10379 -2209 -8109 48>33.3. F. . . .3
[6]
-788 458 1286 -0.0 956 -7384 -3377 10690 -7135 48 33.31 F. . . .3
153 -1739 1254 -0.0 -332 8033 -10377 2200 8111 48 33.31 F. . . .3
581 -458 -1286 0.0 -1163 7376 3379 -10694 7128 48 b3.31 F. . . .3
-155 1738 -1255 0.0 328 -8039 10375 -2198 -8116 48 b3.31 F. . . .3
[7]
-583 454 1283 -0.0 1154 -7373 -3386 10692 -7126 48 b3.31 F. . . .3
154 -1737 1253 0.0 -331 8039 -10377 2191 8120 48 b3.31 F. . . .3
581 -454 -1288 0.0 -1160 7367 3391 -10696 7119 48 b3.31 F. . . .3
-155 1735 -1252 0.0 327 -8044 10373 -2187 -8127 48 b3.31 F. . . .3
[8]
-582 453 1289 0.0 1160 -7367 -3400 10696 -7115 48 b3.31 F. . . .3
154 -1739 1249 -0.0 -337 8048 -10372 2178 8127 48 b3.31 F. . . .3
580 -452 -1291 0.0 -1163 7358 3404 -10699 7108 48 b3.31 F. . . .3
-155 1738 -1249 0.0 333 -8055 10368 -2173 -8134 48 b3.31 F. . . .3
[9]
-584 450 1291 -0.0 1157 -7357 -3411 10699 -7106 48 b3.31 F. . . .3
156 -1738 1247 -0.0 -335 8059 -10370 2165 8136 48 b3.31 F. . . .3
581 -451 -1293 0.0 -1163 7351 3413 -10701 7101 48 b3.31 F. . . .3
-159 1737 -1248 0.0 330 -8064 10366 -2162 -8141 48 b3.31 F. . . .3
[10]
-582 449 1292 -0.0 1159 -7348 -3422 10699 -7097 48 b3.31 F. . . .3
156 -1737 1247 -0.0 -334 8064 -10366 2155 8143 48 b3.31 F. . . .3
580 -450 -1297 -0.0 -1167 7340 3427 -10705 7090 48 b3.31 F. . . .3
-157 1738 -1248 0.0 333 -8071 10361 -2151 -8150 48 b3.31 F. . . .3
[11]
-583 449 1296 0.0 1162 -7339 -3434 10705 -7088 48 b3.31 F. . . .3
156 -1741 1245 -0.0 -340 8073 -10359 2140 8152 48 b3.31 F. . . .3
581 -448 -1295 0.0 -1162 7333 3438 -10706 7083 48 b3.31 F. . . .3
-159 1738 -1246 0.0 333 -8078 10355 -2137 -8158 48 b3.31 F. . . .3
[12]
-583 446 1294 -0.0 1157 -7331 -3445 10706 -7081 48 b3.31 F. . . .3
156 -1519 1243 -0.0 -121 8080 -10355 2128 8159 48 b3.31 F. . . .3
581 -276 -1296 0.0 -991 7322 3449 -10708 7074 48 b3.31 F. . . .3
-158 941 -1243 0.0 -460 -8086 10352 -2124 -8165 48 b3.31 F. . . .3
[13]
-582 124 1296 -0.0 838 -7319 -3456 10706 -7072 48 b3.31 F. . . .3
158 -586 981 -0.0 553 8089 -10354 2117 8168 48 C3.31 F. . . .3
581 -149 -1085 0.0 -652 7313 3461 -10710 7065 48 C3.31 F. . . .3
-160 585 -569 0.0 -145 -8096 10350 -2111 -8174 48 C3.3. F. . . .3
[14]
-583 145 651 -0.0 212 -7310 -3469 10710 -7061 48 C3.3. .. . . .3
158 -585 413 -0.0 -13.8 8096 -10350 2106 8174 48 C3.3. .. . . .3
581 -146 -436 0.0 -0.6 7304 3472 -10714 7056 48 ..... .. . . .3
-159 583 -414 0.0 9.6 -8104 10346 -2102 -8181 48 ..... .. . . .3
[15]
-581 146 435 -0.0 0.0 -7303 -3479 10714 -7052 48 ..... .. . . .3
157 -584 413 -0.0 -14.4 8107 -10346 2093 8183 48 ..... .. . . .3
579 -148 -436 0.0 -4.2 7297 3483 -10715 7047 48 ..... .. . . .3
-158 584 -414 0.0 12.0 -8111 10341 -2088 -8188 48 ..... .. . . ..
One Cycle of Data
Optional Voltage Card Required
Date and Time of Event
See Figure 9.4 and Figure 9.5
