9.11
Date Code 20100129 Instruction Manual SEL-751A Relay
Analyzing Events
Event Reporting
Serial No = 2008xxxxxxxxxxx
FID = SEL-751A-X215-V0-Z003002-D20080530 CID = 0E1E
EVENT LOGS = 2
Event: ER Trigger
Targets 11100001
Freq (Hz) 60.0
Current Mag
IA IB IC IN IG
(A) 1806.6 1796.0 1796.0 0.00 16.94
Voltage Mag
VAN VBN VCN VG
(V) 10910 10916 10916 162
PHROT := ABC FNOM := 60 DATE_F := MDY
FAULT := 50G1P OR 50N1P OR 51P1P OR 51QP OR 50Q1P OR TRIP
EMP := N TGR := 3
SS1 := 1
SS2 := 0
SS3 := 0
52ABF := N BFD := 0.50 BFI := R_TRIG TRIP
AO301AQ :=OFF
DCLOP := OFF DCHIP := OFF
IN101D := 10 IN102D := 10
IN301D := 10 IN302D := 10 IN303D := 10 IN401D := 10
IN402D := 10 IN403D := 10 IN404D := 10
RSTTRGT := 0
RSTENRGY:= 0
RSTMXMN := 0
DSABLSET:= 0
Group Settings
RID := SEL-751A
TID := FEEDER RELAY
CTR := 120 CTRN := 120 PTR := 180.00 PTRS := 180.00
DELTA_Y := WYE VNOM := 120.00 SINGLEV := N
50P1P := 10.00 50P1D := 0.00 50P1TC := 1
50P2P := 10.00 50P2D := 0.00 50P2TC := 1
50P3P := 10.00 50P3D := 0.00 50P3TC := 1
50P4P := 10.00 50P4D := 0.00 50P4TC := 1
50N1P := OFF 50N2P := OFF 50N3P := OFF 50N4P := OFF
50G1P := OFF 50G2P := OFF 50G3P := OFF 50G4P := OFF
50Q1P := OFF 50Q2P := OFF 50Q3P := OFF 50Q4P := OFF
51AP := 6.00
51AC := U3 51ATD := 3.00 51ARS := N
51ACT := 0.00 51AMR := 0.00 51ATC := 1
51BP := 6.00 51BC := U3 51BTD := 3.00 51BRS := N
51BCT := 0.00 51BMR := 0.00 51BTC := 1
51CP := 6.00 51CC := U3 51CTD := 3.00 51CRS := N
51CCT := 0.00 51CMR := 0.00 51CTC := 1
51P1P := 6.00 51P1C := U3 51P1TD := 3.00 51P1RS := N
51P1CT := 0.00 51P1MR := 0.00 51P1TC := 1
51P2P := 6.00 51P2C := U3 51P2TD := 3.00 51P2RS := N
51P2CT := 0.00 51P2MR := 0.00 51P2TC := 1
51QP := 6.00 51QC := U3 51QTD := 3.00 51QRS := N
51QCT := 0.00 51QMR := 0.00 51QTC := 1
51N1P := OFF 51N2P := OFF 51G1P := 0.50 51G1C := U3
51G1TD := 1.50 51G1RS := N
51G1CT := 0.00 51G1MR := 0.00 51G1TC := 1
51G2P := 0.50 51G2C := U3 51G2TD := 1.50 51G2RS := N
51G2CT := 0.00 51G2MR := 0.00 51G2TC := 1
E49RTD := NONE
27P1P := OFF 27P2P := OFF 27S1P := OFF 27S2P := OFF
59P1P := 1.10 59P1D := 0.5 59P2P := OFF 59S1P := OFF
59S2P := OFF
Firmware Checksum Identifier
Firmware Identifier
