E.11

Date Code 20100129 Instruction Manual SEL-751A Relay

Modbus RTU Communications

Communications Protocol

6 01, 05 Pulse OUT304 1 second

701, 05Reserved

801, 05Reserved

901, 05Reserved

10 01, 05 Reserved

11 01, 05 Pulse OUT401 1 second

12 01, 05 Pulse OUT402 1 second

13 01, 05 Pulse OUT403 1 second

14 01, 05 Pulse OUT404 1 second

15 01, 05 Reserved

16 01, 05 Reserved

17 01, 05 Reserved

18 01, 05 Reserved

19 01, 05 Pulse OUT501 1 second

20 01, 05 Pulse OUT502 1 second

21 01, 05 Pulse OUT503 1 second

22 01, 05 Pulse OUT504 1 second

23 01, 05 Reserved

24 01, 05 Reserved

25 01, 05 Reserved

26 01, 05 Reserved

27 01, 05 RB01

28 01, 05 RB02

29 01, 05 RB03

30 01, 05 RB04

31 01, 05 RB05

32 01, 05 RB06

33 01, 05 RB07

34 01, 05 RB08

35 01, 05 RB09

36 01, 05 RB10

37 01, 05 RB11

38 01, 05 RB12

39 01, 05 RB13

Table E.14 01h, 05h SEL-751A Output (Sheet 2 of 4)
