Sel 751A - Page 474

To Next Page

To Previous Page

E.12

SEL-751A Relay Instruction Manual Date Code 20100129

Modbus RTU Communications

Communications Protocol

40 01, 05 RB14

41 01, 05 RB15

42 01, 05 RB16

43 01, 05 RB17

44 01, 05 RB18

45 01, 05 RB19

46 01, 05 RB20

47 01, 05 RB21

48 01, 05 RB22

49 01, 05 RB23

50 01, 05 RB24

51 01, 05 RB25

52 01, 05 RB26

53 01, 05 RB27

54 01, 05 RB28

55 01, 05 RB29

56 01, 05 RB30

57 01, 05 RB31

58 01, 05 RB32

59 01, 05 Pulse RB01

60 01, 05 Pulse RB02

61 01, 05 Pulse RB03

62 01, 05 Pulse RB04

63 01, 05 Pulse RB05

64 01, 05 Pulse RB06

65 01, 05 Pulse RB07

66 01, 05 Pulse RB08

67 01, 05 Pulse RB09

68 01, 05 Pulse RB10

69 01, 05 Pulse RB11

70 01, 05 Pulse RB12

71 01, 05 Pulse RB13

72 01, 05 Pulse RB14

73 01, 05 Pulse RB15

Table E.14 01h, 05h SEL-751A Output (Sheet 3 of 4)
