E.45
Date Code 20100129 Instruction Manual SEL-751A Relay
Modbus RTU Communications
Modbus Register Map
786 (R) IC MIN TIME ss 0 5999 0 0.01 886
787 (R) IC MIN TIME mm 0 59 0 1 887
788 (R) IC MIN TIME hh 0 23 0 1 888
789 (R) IC MIN DAY dd 1 31 1 1 889
790 (R) IC MIN DAY mm 1 12 1 1 890
791 (R) IC MIN DAY yy 2000 9999 2000 1 891
792 (R) IN MAX A 0 65535 0 1 892
793 (R) IN MAX TIME ss 0 5999 0 0.01 893
794 (R) IN MAX TIME mm 0 59 0 1 894
795 (R) IN MAX TIME hh 0 23 0 1 895
796 (R) IN MAX DAY dd 1 31 1 1 896
797 (R) IN MAX DAY mm 1 12 1 1 897
798 (R) IN MAX DAY yy 2000 9999 2000 1 898
799 (R) IN MIN A 0 65535 0 1 899
800 (R) IN MIN TIME ss 0 5999 0 0.01 900
801 (R) IN MIN TIME mm 0 59 0 1 901
802 (R) IN MIN TIME hh 0 23 0 1 902
803 (R) IN MIN DAY dd 1 31 1 1 903
804 (R) IN MIN DAY mm 1 12 1 1 904
805 (R) IN MIN DAY yy 2000 9999 2000 1 905
806 (R) IG MAX A 0 65535 0 1 906
807 (R) IG MAX TIME ss 0 5999 0 0.01 907
808 (R) IG MAX TIME mm 0 59 0 1 908
809 (R) IG MAX TIME hh 0 23 0 1 909
810 (R) IG MAX DAY dd 1 31 1 1 910
811 (R) IG MAX DAY mm 1 12 1 1 911
812 (R) IG MAX DAY yy 2000 9999 2000 1 912
813 (R) IG MIN A 0 65535 0 1 913
814 (R) IG MIN TIME ss 0 5999 0 0.01 914
815 (R) IG MIN TIME mm 0 59 0 1 915
816 (R) IG MIN TIME hh 0 23 0 1 916
817 (R) IG MIN DAY dd 1 31 1 1 917
818 (R) IG MIN DAY mm 1 12 1 1 918
819 (R) IG MIN DAY yy 2000 9999 2000 1 919
820 (R) VAB/VA MAX V 0 65535 0 1 920
821 (R) VAB/VA MX TIM ss 0 5999 0 0.01 921
822 (R) VAB/VA MX TIM mm 0 59 0 1 922
823 (R) VAB/VA MX TIM hh 0 23 0 1 923
824 (R) VAB/VA MX DAY dd 1 31 1 1 924
825 (R) VAB/VA MX DAY mm 1 12 1 1 925
826 (R) VAB/VA MX DAY yy 2000 9999 2000 1 926
827 (R) VAB/VA MIN V 0 65535 0 1 927
828 (R) VAB/VA MN TIM ss 0 5999 0 0.01 928
Table E.32 Modbus Register Map
a
(Sheet 20 of 56)
Modbus Register
Address
b
Name/Enums Units Min Max Default
Scale
Facto r
DeviceNet
Parameter
Numbers
