E.46
SEL-751A Relay Instruction Manual Date Code 20100129
Modbus RTU Communications
Modbus Register Map
829 (R) VAB/VA MN TIM mm 0 59 0 1 929
830 (R) VAB/VA MN TIM hh 0 23 0 1 930
831 (R) VAB/VA MN DAY dd 1 31 1 1 931
832 (R) VAB/VA MN DAY mm 1 12 1 1 932
833 (R) VAB/VA MN DAY yy 2000 9999 2000 1 933
834 (R) VBC/VB MAX V 0 65535 0 1 934
835 (R) VBC/VB MX TIM ss 0 5999 0 0.01 935
836 (R) VBC/VB MX TIM mm 0 59 0 1 936
837 (R) VBC/VB MX TIM hh 0 23 0 1 937
838 (R) VBC/VB MX DAY dd 1 31 1 1 938
839 (R) VBC/VB MX DAY mm 1 12 1 1 939
840 (R) VBC/VB MX DAY yy 2000 9999 2000 1 940
841 (R) VBC/VB MIN V 0 65535 0 1 941
842 (R) VBC/VB MN TIM ss 0 5999 0 0.01 942
843 (R) VBC/VB MN TIM mm 0 59 0 1 943
844 (R) VBC/VB MN TIM hh 0 23 0 1 944
845 (R) VBC/VB MN DAY dd 1 31 1 1 945
846 (R) VBC/VB MN DAY mm 1 12 1 1 946
847 (R) VBC/VB MN DAY yy 2000 9999 2000 1 947
848 (R) VCA/VC MAX V 0 65535 0 1 948
849 (R) VCA/VC MX TIM ss 0 5999 0 0.01 949
850 (R) VCA/VC MX TIM mm 0 59 0 1 950
851 (R) VCA/VC MX TIM hh 0 23 0 1 951
852 (R) VCA/VC MX DAY dd 1 31 1 1 952
853 (R) VCA/VC MX DAY mm 1 12 1 1 953
854 (R) VCA/VC MX DAY yy 2000 9999 2000 1 954
855 (R) VCA/VC MIN V 0 65535 0 1 955
856 (R) VCA/VC MN TIM ss 0 5999 0 0.01 956
857 (R) VCA/VC MN TIM mm 0 59 0 1 957
858 (R) VCA/VC MN TIM hh 0 23 0 1 958
859 (R) VCA/VC MN DAY dd 1 31 1 1 959
860 (R) VCA/VC MN DAY mm 1 12 1 1 960
861 (R) VCA/VC MN DAY yy 2000 9999 2000 1 961
862 (R) KW3P MAX kW –32768 32767 0 1 962
863 (R) KW3P MX TIM ss 0 5999 0 0.01 963
864 (R) KW3P MX TIM mm 0 59 0 1 964
865 (R) KW3P MX TIM hh 0 23 0 1 965
866 (R) KW3P MX DAY dd 1 31 1 1 966
867 (R) KW3P MX DAY mm 1 12 1 1 967
868 (R) KW3P MX DAY yy 2000 9999 2000 1 968
869 (R) KW3P MIN kW –32768 32767 0 1 969
870 (R) KW3P MN TIM ss 0 5999 0 0.01 970
871 (R) KW3P MN TIM mm 0 59 0 1 971
Table E.32 Modbus Register Map
a
(Sheet 21 of 56)
Modbus Register
Address
b
Name/Enums Units Min Max Default
Scale
Facto r
DeviceNet
Parameter
Numbers
