E.47
Date Code 20100129 Instruction Manual SEL-751A Relay
Modbus RTU Communications
Modbus Register Map
872 (R) KW3P MN TIM hh 0 23 0 1 972
873 (R) KW3P MN DAY dd 1 31 1 1 973
874 (R) KW3P MN DAY mm 1 12 1 1 974
875 (R) KW3P MN DAY yy 2000 9999 2000 1 975
876 (R) KVAR3P MAX kVAR –32768 32767 0 1 976
877 (R) KVAR3P MX TIM ss 0 5999 0 0.01 977
878 (R) KVAR3P MX TIM mm 0 59 0 1 978
879 (R) KVAR3P MX TIM hh 0 23 0 1 979
880 (R) KVAR3P MX DAY dd 1 31 1 1 980
881 (R) KVAR3P MX DAY mm 1 12 1 1 981
882 (R) KVAR3P MX DAY yy 2000 9999 2000 1 982
883 (R) KVAR3P MIN kVAR –32768 32767 0 1 983
884 (R) KVAR3P MN TIM ss 0 5999 0 0.01 984
885 (R) KVAR3P MN TIM mm 0 59 0 1 985
886 (R) KVAR3P MN TIM hh 0 23 0 1 986
887 (R) KVAR3P MN DAY dd 1 31 1 1 987
888 (R) KVAR3P MN DAY mm 1 12 1 1 988
889 (R) KVAR3P MN DAY yy 2000 9999 2000 1 989
890 (R) KVA3P MAX kVA –32768 32767 0 1 990
891 (R) KVA3P MX TIM ss 0 5999 0 0.01 991
892 (R) KVA3P MX TIM mm 0 59 0 1 992
893 (R) KVA3P MX TIM hh 0 23 0 1 993
894 (R) KVA3P MX DAY dd 1 31 1 1 994
895 (R) KVA3P MX DAY mm 1 12 1 1 995
896 (R) KVA3P MX DAY yy 2000 9999 2000 1 996
897 (R) KVA3P MIN kVA –32768 32767 0 1 997
898 (R) KVA3P MN TIM ss 0 5999 0 0.01 998
899 (R) KVA3P MN TIM mm 0 59 0 1 999
900 (R) KVA3P MN TIM hh 0 23 0 1 1000
901 (R) KVA3P MN DAY dd 1 31 1 1 1001
902 (R) KVA3P MN DAY mm 1 12 1 1 1002
903 (R) KVA3P MN DAY yy 2000 9999 2000 1 1003
904 (R) FREQ MAX Hz 0 65535 0 0.01 1004
905 (R) FREQ MX TIM ss 0 5999 0 0.01 1005
906 (R) FREQ MX TIM mm 0 59 0 1 1006
907 (R) FREQ MX TIM hh 0 23 0 1 1007
908 (R) FREQ MX DAY dd 1 31 1 1 1008
909 (R) FREQ MX DAY mm 1 12 1 1 1009
910 (R) FREQ MX DAY yy 2000 9999 2000 1 1010
911 (R) FREQ MIN Hz 0 65535 0 0.01 1011
912 (R) FREQ MN TIM ss 0 5999 0 0.01 1012
913 (R) FREQ MN TIM mm 0 59 0 1 1013
914 (R) FREQ MN TIM hh 0 23 0 1 1014
Table E.32 Modbus Register Map
a
(Sheet 22 of 56)
Modbus Register
Address
b
Name/Enums Units Min Max Default
Scale
Facto r
DeviceNet
Parameter
Numbers
