Sel 751A - Page 513

E.51
Date Code 20100129 Instruction Manual SEL-751A Relay
Modbus RTU Communications
Modbus Register Map
1043 (R) RTD9 MN DAY yy 2000 9999 2000 1 1143
1044 (R) RTD10 MAX degC –32768 32767 0 1 1144
1045 (R) RTD10 MX TIM ss 0 5999 0 0.01 1145
1046 (R) RTD10 MX TIM mm 0 59 0 1 1146
1047 (R) RTD10 MX TIM hh 0 23 0 1 1147
1048 (R) RTD10 MX DAY dd 1 31 1 1 1148
1049 (R) RTD10 MX DAY mm 1 12 1 1 1149
1050 (R) RTD10 MX DAY yy 2000 9999 2000 1 1150
1051 (R) RTD10 MIN degC –32768 32767 0 1 1151
1052 (R) RTD10 MN TIM ss 0 5999 0 0.01 1152
1053 (R) RTD10 MN TIM mm 0 59 0 1 1153
1054 (R) RTD10 MN TIM hh 0 23 0 1 1154
1055 (R) RTD10 MN DAY dd 1 31 1 1 1155
1056 (R) RTD10 MN DAY mm 1 12 1 1 1156
1057 (R) RTD10 MN DAY yy 2000 9999 2000 1 1157
1058 (R) RTD11 MAX degC –32768 32767 0 1 1158
1059 (R) RTD11 MX TIM ss 0 5999 0 0.01 1159
1060 (R) RTD11 MX TIM mm 0 59 0 1 1160
1061 (R) RTD11 MX TIM hh 0 23 0 1 1161
1062 (R) RTD11 MX DAY dd 1 31 1 1 1162
1063 (R) RTD11 MX DAY mm 1 12 1 1 1163
1064 (R) RTD11 MX DAY yy 2000 9999 2000 1 1164
1065 (R) RTD11 MIN degC –32768 32767 0 1 1165
1066 (R) RTD11 MN TIM ss 0 5999 0 0.01 1166
1067 (R) RTD11 MN TIM mm 0 59 0 1 1167
1068 (R) RTD11 MN TIM hh 0 23 0 1 1168
1069 (R) RTD11 MN DAY dd 1 31 1 1 1169
1070 (R) RTD11 MN DAY mm 1 12 1 1 1170
1071 (R) RTD11 MN DAY yy 2000 9999 2000 1 1171
1072 (R) RTD12 MAX degC –32768 32767 0 1 1172
1073 (R) RTD12 MX TIM ss 0 5999 0 0.01 1173
1074 (R) RTD12 MX TIM mm 0 59 0 1 1174
1075 (R) RTD12 MX TIM hh 0 23 0 1 1175
1076 (R) RTD12 MX DAY dd 1 31 1 1 1176
1077 (R) RTD12 MX DAY mm 1 12 1 1 1177
1078 (R) RTD12 MX DAY yy 2000 9999 2000 1 1178
1079 (R) RTD12 MIN degC –32768 32767 0 1 1179
1080 (R) RTD12 MN TIM ss 0 5999 0 0.01 1180
1081 (R) RTD12 MN TIM mm 0 59 0 1 1181
1082 (R) RTD12 MN TIM hh 0 23 0 1 1182
1083 (R) RTD12 MN DAY dd 1 31 1 1 1183
Table E.32 Modbus Register Map
a
(Sheet 26 of 56)
Modbus Register
Address
b
Name/Enums Units Min Max Default
Scale
Facto r
DeviceNet
Parameter
Numbers
