SEL-751A Relay Instruction Manual Date Code 20100129
Modbus RTU Communications
Modbus Register Map
1084 (R) RTD12 MN DAY mm 1 12 1 1 1184
1085 (R) RTD12 MN DAY yy 2000 9999 2000 1 1185
MAX/MIN AI3 Data
1086 (R) AI301 MX–HI EU –32768 32767 0 0.001 1186
1087 (R) AI301 MX–LO EU –32768 32767 0 0.001 1187
1088 (R) AI301 MX TIM ss 0 5999 0 0.01 1188
1089 (R) AI301 MX TIM mm 0 59 0 1 1189
1090 (R) AI301 MX TIM hh 0 23 0 1 1190
1091 (R) AI301 MX DAY dd 1 31 1 1 1191
1092 (R) AI301 MX DAY mm 1 12 1 1 1192
1093 (R) AI301 MX DAY yy 2000 9999 2000 1 1193
1094 (R) AI301 MN–HI EU –32768 32767 0 0.001 1194
1095 (R) AI301 MN–LO EU –32768 32767 0 0.001 1195
1096 (R) AI301 MN TIM ss 0 5999 0 0.01 1196
1097 (R) AI301 MN TIM mm 0 59 0 1 1197
1098 (R) AI301 MN TIM hh 0 23 0 1 1198
1099 (R) AI301 MN DAY dd 1 31 1 1 1199
1100 (R) AI301 MN DAY mm 1 12 1 1 1200
1101 (R) AI301 MN DAY yy 2000 9999 2000 1 1201
1102 (R) AI302 MX–HI EU –32768 32767 0 0.001 1202
1103 (R) AI302 MX–LO EU –32768 32767 0 0.001 1203
1104 (R) AI302 MX TIM ss 0 5999 0 0.01 1204
1105 (R) AI302 MX TIM mm 0 59 0 1 1205
1106 (R) AI302 MX TIM hh 0 23 0 1 1206
1107 (R) AI302 MX DAY dd 1 31 1 1 1207
1108 (R) AI302 MX DAY mm 1 12 1 1 1208
1109 (R) AI302 MX DAY yy 2000 9999 2000 1 1209
1110 (R) AI302 MN–HI EU –32768 32767 0 0.001 1210
1111 (R) AI302 MN–LO EU –32768 32767 0 0.001 1211
1112 (R) AI302 MN TIM ss 0 5999 0 0.01 1212
1113 (R) AI302 MN TIM mm 0 59 0 1 1213
1114 (R) AI302 MN TIM hh 0 23 0 1 1214
1115 (R) AI302 MN DAY dd 1 31 1 1 1215
1116 (R) AI302 MN DAY mm 1 12 1 1 1216
1117 (R) AI302 MN DAY yy 2000 9999 2000 1 1217
1118 (R) AI303 MX–HI EU –32768 32767 0 0.001 1218
1119 (R) AI303 MX–LO EU –32768 32767 0 0.001 1219
1120 (R) AI303 MX TIM ss 0 5999 0 0.01 1220
1121 (R) AI303 MX TIM mm 0 59 0 1 1221
1122 (R) AI303 MX TIM hh 0 23 0 1 1222
1123 (R) AI303 MX DAY dd 1 31 1 1 1223
1124 (R) AI303 MX DAY mm 1 12 1 1 1224
Table E.32 Modbus Register Map
a
(Sheet 27 of 56)
Modbus Register
Address
b
Name/Enums Units Min Max Default
Scale
Facto r
DeviceNet
Parameter
Numbers
