E.53
Date Code 20100129 Instruction Manual SEL-751A Relay
Modbus RTU Communications
Modbus Register Map
1125 (R) AI303 MX DAY yy 2000 9999 2000 1 1225
1126 (R) AI303 MN–HI EU –32768 32767 0 0.001 1226
1127 (R) AI303 MN–LO EU –32768 32767 0 0.001 1227
1128 (R) AI303 MN TIM ss 0 5999 0 0.01 1228
1129 (R) AI303 MN TIM mm 0 59 0 1 1229
1130 (R) AI303 MN TIM hh 0 23 0 1 1230
1131 (R) AI303 MN DAY dd 1 31 1 1 1231
1132 (R) AI303 MN DAY mm 1 12 1 1 1232
1133 (R) AI303 MN DAY yy 2000 9999 2000 1 1233
1134 (R) AI304 MX–HI EU –32768 32767 0 0.001 1234
1135 (R) AI304 MX–LO EU –32768 32767 0 0.001 1235
1136 (R) AI304 MX TIM ss 0 5999 0 0.01 1236
1137 (R) AI304 MX TIM mm 0 59 0 1 1237
1138 (R) AI304 MX TIM hh 0 23 0 1 1238
1139 (R) AI304 MX DAY dd 1 31 1 1 1239
1140 (R) AI304 MX DAY mm 1 12 1 1 1240
1141 (R) AI304 MX DAY yy 2000 9999 2000 1 1241
1142 (R) AI304 MN–HI EU –32768 32767 0 0.001 1242
1143 (R) AI304 MN–LO EU –32768 32767 0 0.001 1243
1144 (R) AI304 MN TIM ss 0 5999 0 0.01 1244
1145 (R) AI304 MN TIM mm 0 59 0 1 1245
1146 (R) AI304 MN TIM hh 0 23 0 1 1246
1147 (R) AI304 MN DAY dd 1 31 1 1 1247
1148 (R) AI304 MN DAY mm 1 12 1 1 1248
1149 (R) AI304 MN DAY yy 2000 9999 2000 1 1249
1150 (R) AI305 MX–HI EU –32768 32767 0 0.001 1250
1151 (R) AI305 MX–LO EU –32768 32767 0 0.001 1251
1152 (R) AI305 MX TIM ss 0 5999 0 0.01 1252
1153 (R) AI305 MX TIM mm 0 59 0 1 1253
1154 (R) AI305 MX TIM hh 0 23 0 1 1254
1155 (R) AI305 MX DAY dd 1 31 1 1 1255
1156 (R) AI305 MX DAY mm 1 12 1 1 1256
1157 (R) AI305 MX DAY yy 2000 9999 2000 1 1257
1158 (R) AI305 MN–HI EU –32768 32767 0 0.001 1258
1159 (R) AI305 MN–LO EU –32768 32767 0 0.001 1259
1160 (R) AI305 MN TIM ss 0 5999 0 0.01 1260
1161 (R) AI305 MN TIM mm 0 59 0 1 1261
1162 (R) AI305 MN TIM hh 0 23 0 1 1262
1163 (R) AI305 MN DAY dd 1 31 1 1 1263
1164 (R) AI305 MN DAY mm 1 12 1 1 1264
1165 (R) AI305 MN DAY yy 2000 9999 2000 1 1265
Table E.32 Modbus Register Map
a
(Sheet 28 of 56)
Modbus Register
Address
b
Name/Enums Units Min Max Default
Scale
Facto r
DeviceNet
Parameter
Numbers
