E.54
SEL-751A Relay Instruction Manual Date Code 20100129
Modbus RTU Communications
Modbus Register Map
1166 (R) AI306 MX–HI EU –32768 32767 0 0.001 1266
1167 (R) AI306 MX–LO EU –32768 32767 0 0.001 1267
1168 (R) AI306 MX TIM ss 0 5999 0 0.01 1268
1169 (R) AI306 MX TIM mm 0 59 0 1 1269
1170 (R) AI306 MX TIM hh 0 23 0 1 1270
1171 (R) AI306 MX DAY dd 1 31 1 1 1271
1172 (R) AI306 MX DAY mm 1 12 1 1 1272
1173 (R) AI306 MX DAY yy 2000 9999 2000 1 1273
1174 (R) AI306 MN–HI EU –32768 32767 0 0.001 1274
1175 (R) AI306 MN–LO EU –32768 32767 0 0.001 1275
1176 (R) AI306 MN TIM ss 0 5999 0 0.01 1276
1177 (R) AI306 MN TIM mm 0 59 0 1 1277
1178 (R) AI306 MN TIM hh 0 23 0 1 1278
1179 (R) AI306 MN DAY dd 1 31 1 1 1279
1180 (R) AI306 MN DAY mm 1 12 1 1 1280
1181 (R) AI306 MN DAY yy 2000 9999 2000 1 1281
1182 (R) AI307 MX–HI EU –32768 32767 0 0.001 1282
1183 (R) AI307 MX–LO EU –32768 32767 0 0.001 1283
1184 (R) AI307 MX TIM ss 0 5999 0 0.01 1284
1185 (R) AI307 MX TIM mm 0 59 0 1 1285
1186 (R) AI307 MX TIM hh 0 23 0 1 1286
1187 (R) AI307 MX DAY dd 1 31 1 1 1287
1188 (R) AI307 MX DAY mm 1 12 1 1 1288
1189 (R) AI307 MX DAY yy 2000 9999 2000 1 1289
1190 (R) AI307 MN–HI EU –32768 32767 0 0.001 1290
1191 (R) AI307 MN–LO EU –32768 32767 0 0.001 1291
1192 (R) AI307 MN TIM ss 0 5999 0 0.01 1292
1193 (R) AI307 MN TIM mm 0 59 0 1 1293
1194 (R) AI307 MN TIM hh 0 23 0 1 1294
1195 (R) AI307 MN DAY dd 1 31 1 1 1295
1196 (R) AI307 MN DAY mm 1 12 1 1 1296
1197 (R) AI307 MN DAY yy 2000 9999 2000 1 1297
1198 (R) AI308 MX–HI EU –32768 32767 0 0.001 1298
1199 (R) AI308 MX–LO EU –32768 32767 0 0.001 1299
1200 (R) AI308 MX TIM ss 0 5999 0 0.01 1300
1201 (R) AI308 MX TIM mm 0 59 0 1 1301
1202 (R) AI308 MX TIM hh 0 23 0 1 1302
1203 (R) AI308 MX DAY dd 1 31 1 1 1303
1204 (R) AI308 MX DAY mm 1 12 1 1 1304
1205 (R) AI308 MX DAY yy 2000 9999 2000 1 1305
Table E.32 Modbus Register Map
a
(Sheet 29 of 56)
Modbus Register
Address
b
Name/Enums Units Min Max Default
Scale
Facto r
DeviceNet
Parameter
Numbers
