Modbus Register Map
1206 (R) AI308 MN–HI EU –32768 32767 0.001 0.001 1306
1207 (R) AI308 MN–LO EU –32768 32767 0.001 0.001 1307
1208 (R) AI308 MN TIM ss 0 5999 0.01 0.01 1308
1209 (R) AI308 MN TIM mm 0 59 1 1 1309
1210 (R) AI308 MN TIM hh 0 23 1 1 1310
1211 (R) AI308 MN DAY dd 1 31 1 1 1311
1212 (R) AI308 MN DAY mm 1 12 1 1 1312
1213 (R) AI308 MN DAY yy 2000 9999 1 1 1313
MAX/MIN AI4 Data
1214 (R) AI401 MX–HI EU –32768 32767 1 0.001 1314
1215 (R) AI401 MX–LO EU –32768 32767 0 0.001 1315
1216 (R) AI401 MX TIM ss 0 5999 0 0.01 1316
1217 (R) AI401 MX TIM mm 0 59 0 1 1317
1218 (R) AI401 MX TIM hh 0 23 0 1 1318
1219 (R) AI401 MX DAY dd 1 31 1 1 1319
1220 (R) AI401 MX DAY mm 1 12 1 1 1320
1221 (R) AI401 MX DAY yy 2000 9999 2000 1 1321
1222 (R) AI401 MN–HI EU –32768 32767 0 0.001 1322
1223 (R) AI401 MN–LO EU –32768 32767 0 0.001 1323
1224 (R) AI401 MN TIM ss 0 5999 0 0.01 1324
1225 (R) AI401 MN TIM mm 0 59 0 1 1325
1226 (R) AI401 MN TIM hh 0 23 0 1 1326
1227 (R) AI401 MN DAY dd 1 31 1 1 1327
1228 (R) AI401 MN DAY mm 1 12 1 1 1328
1229 (R) AI401 MN DAY yy 2000 9999 2000 1 1329
1230 (R) AI402 MX–HI EU –32768 32767 0 0.001 1330
1231 (R) AI402 MX–LO EU –32768 32767 0 0.001 1331
1232 (R) AI402 MX TIM ss 0 5999 0 0.01 1332
1233 (R) AI402 MX TIM mm 0 59 0 1 1333
1234 (R) AI402 MX TIM hh 0 23 0 1 1334
1235 (R) AI402 MX DAY dd 1 31 1 1 1335
1236 (R) AI402 MX DAY mm 1 12 1 1 1336
1237 (R) AI402 MX DAY yy 2000 9999 2000 1 1337
1238 (R) AI402 MN–HI EU –32768 32767 0 0.001 1338
1239 (R) AI402 MN–LO EU –32768 32767 0 0.001 1339
1240 (R) AI402 MN TIM ss 0 5999 0 0.01 1340
1241 (R) AI402 MN TIM mm 0 59 0 1 1341
1242 (R) AI402 MN TIM hh 0 23 0 1 1342
1243 (R) AI402 MN DAY dd 1 31 1 1 1343
1244 (R) AI402 MN DAY mm 1 12 1 1 1344
1245 (R) AI402 MN DAY yy 2000 9999 2000 1 1345
