E.56
SEL-751A Relay Instruction Manual Date Code 20100129
Modbus RTU Communications
Modbus Register Map
1246 (R) AI403 MX–HI EU –32768 32767 0 0.001 1346
1247 (R) AI403 MX–LO EU –32768 32767 0 0.001 1347
1248 (R) AI403 MX TIM ss 0 5999 0 0.01 1348
1249 (R) AI403 MX TIM mm 0 59 0 1 1349
1250 (R) AI403 MX TIM hh 0 23 0 1 1350
1251 (R) AI403 MX DAY dd 1 31 1 1 1351
1252 (R) AI403 MX DAY mm 1 12 1 1 1352
1253 (R) AI403 MX DAY yy 2000 9999 2000 1 1353
1254 (R) AI403 MN–HI EU –32768 32767 0 0.001 1354
1255 (R) AI403 MN–LO EU –32768 32767 0 0.001 1355
1256 (R) AI403 MN TIM ss 0 5999 0 0.01 1356
1257 (R) AI403 MN TIM mm 0 59 0 1 1357
1258 (R) AI403 MN TIM hh 0 23 0 1 1358
1259 (R) AI403 MN DAY dd 1 31 1 1 1359
1260 (R) AI403 MN DAY mm 1 12 1 1 1360
1261 (R) AI403 MN DAY yy 2000 9999 2000 1 1361
1262 (R) AI404 MX–HI EU –32768 32767 0 0.001 1362
1263 (R) AI404 MX–LO EU –32768 32767 0 0.001 1363
1264 (R) AI404 MX TIM ss 0 5999 0 0.01 1364
1265 (R) AI404 MX TIM mm 0 59 0 1 1365
1266 (R) AI404 MX TIM hh 0 23 0 1 1366
1267 (R) AI404 MX DAY dd 1 31 1 1 1367
1268 (R) AI404 MX DAY mm 1 12 1 1 1368
1269 (R) AI404 MX DAY yy 2000 9999 2000 1 1369
1270 (R) AI404 MN–HI EU –32768 32767 0 0.001 1370
1271 (R) AI404 MN–LO EU –32768 32767 0 0.001 1371
1272 (R) AI404 MN TIM ss 0 5999 0 0.01 1372
1273 (R) AI404 MN TIM mm 0 59 0 1 1373
1274 (R) AI404 MN TIM hh 0 23 0 1 1374
1275 (R) AI404 MN DAY dd 1 31 1 1 1375
1276 (R) AI404 MN DAY mm 1 12 1 1 1376
1277 (R) AI404 MN DAY yy 2000 9999 2000 1 1377
1278 (R) AI405 MX–HI EU –32768 32767 0 0.001 1378
1279 (R) AI405 MX–LO EU –32768 32767 0 0.001 1379
1280 (R) AI405 MX TIM ss 0 5999 0 0.01 1380
1281 (R) AI405 MX TIM mm 0 59 0 1 1381
1282 (R) AI405 MX TIM hh 0 23 0 1 1382
1283 (R) AI405 MX DAY dd 1 31 1 1 1383
1284 (R) AI405 MX DAY mm 1 12 1 1 1384
1285 (R) AI405 MX DAY yy 2000 9999 2000 1 1385
Table E.32 Modbus Register Map
a
(Sheet 31 of 56)
Modbus Register
Address
b
Name/Enums Units Min Max Default
Scale
Facto r
DeviceNet
Parameter
Numbers
