Modbus RTU Communications
Modbus Register Map
1286 (R) AI405 MN–HI EU –32768 32767 0 0.001 1386
1287 (R) AI405 MN–LO EU –32768 32767 0 0.001 1387
1288 (R) AI405 MN TIM ss 0 5999 0 0.01 1388
1289 (R) AI405 MN TIM mm 0 59 0 1 1389
1290 (R) AI405 MN TIM hh 0 23 0 1 1390
1291 (R) AI405 MN DAY dd 1 31 1 1 1391
1292 (R) AI405 MN DAY mm 1 12 1 1 1392
1293 (R) AI405 MN DAY yy 2000 9999 2000 1 1393
1294 (R) AI406 MX–HI EU –32768 32767 0 0.001 1394
1295 (R) AI406 MX–LO EU –32768 32767 0 0.001 1395
1296 (R) AI406 MX TIM ss 0 5999 0 0.01 1396
1297 (R) AI406 MX TIM mm 0 59 0 1 1397
1298 (R) AI406 MX TIM hh 0 23 0 1 1398
1299 (R) AI406 MX DAY dd 1 31 1 1 1399
1300 (R) AI406 MX DAY mm 1 12 1 1 1400
1301 (R) AI406 MX DAY yy 2000 9999 2000 1 1401
1302 (R) AI406 MN–HI EU –32768 32767 0 0.001 1402
1303 (R) AI406 MN–LO EU –32768 32767 0 0.001 1403
1304 (R) AI406 MN TIM ss 0 5999 0 0.01 1404
1305 (R) AI406 MN TIM mm 0 59 0 1 1405
1306 (R) AI406 MN TIM hh 0 23 0 1 1406
1307 (R) AI406 MN DAY dd 1 31 1 1 1407
1308 (R) AI406 MN DAY mm 1 12 1 1 1408
1309 (R) AI406 MN DAY yy 2000 9999 2000 1 1409
1310 (R) AI407 MX–HI EU –32768 32767 0 0.001 1410
1311 (R) AI407 MX–LO EU –32768 32767 0 0.001 1411
1312 (R) AI407 MX TIM ss 0 5999 0 0.01 1412
1313 (R) AI407 MX TIM mm 0 59 0 1 1413
1314 (R) AI407 MX TIM hh 0 23 0 1 1414
1315 (R) AI407 MX DAY dd 1 31 1 1 1415
1316 (R) AI407 MX DAY mm 1 12 1 1 1416
1317 (R) AI407 MX DAY yy 2000 9999 2000 1 1417
1318 (R) AI407 MN–HI EU –32768 32767 0 0.001 1418
1319 (R) AI407 MN–LO EU –32768 32767 0 0.001 1419
1320 (R) AI407 MN TIM ss 0 5999 0 0.01 1420
1321 (R) AI407 MN TIM mm 0 59 0 1 1421
1322 (R) AI407 MN TIM hh 0 23 0 1 1422
1323 (R) AI407 MN DAY dd 1 31 1 1 1423
1324 (R) AI407 MN DAY mm 1 12 1 1 1424
1325 (R) AI407 MN DAY yy 2000 9999 2000 1 1425
Table E.32 Modbus Register Map
a
(Sheet 32 of 56)
Modbus Register
Address
b
Name/Enums Units Min Max Default
Scale
Facto r
DeviceNet
Parameter
Numbers
