E.58
SEL-751A Relay Instruction Manual Date Code 20100129
Modbus RTU Communications
Modbus Register Map
1326 (R) AI408 MX–HI EU –32768 32767 0 0.001 1426
1327 (R) AI408 MX–LO EU –32768 32767 0 0.001 1427
1328 (R) AI408 MX TIM ss 0 5999 0 0.01 1428
1329 (R) AI408 MX TIM mm 0 59 0 1 1429
1330 (R) AI408 MX TIM hh 0 23 0 1 1430
1331 (R) AI408 MX DAY dd 1 31 1 1 1431
1332 (R) AI408 MX DAY mm 1 12 1 1 1432
1333 (R) AI408 MX DAY yy 2000 9999 2000 1 1433
1334 (R) AI408 MN–HI EU –32768 32767 0 0.001 1434
1335 (R) AI408 MN–LO EU –32768 32767 0 0.001 1435
1336 (R) AI408 MN TIM ss 0 5999 0 0.01 1436
1337 (R) AI408 MN TIM mm 0 59 0 1 1437
1338 (R) AI408 MN TIM hh 0 23 0 1 1438
1339 (R) AI408 MN DAY dd 1 31 1 1 1439
1340 (R) AI408 MN DAY mm 1 12 1 1 1440
1341 (R) AI408 MN DAY yy 2000 9999 2000 1 1441
MAX/MIN AI5 Data
1342 (R) AI501 MX–HI EU –32768 32767 0 0.001 1442
1343 (R) AI501 MX–LO EU –32768 32767 0 0.001 1443
1344 (R) AI501 MX TIM ss 0 5999 0 0.01 1444
1345 (R) AI501 MX TIM mm 0 59 0 1 1445
1346 (R) AI501 MX TIM hh 0 23 0 1 1446
1347 (R) AI501 MX DAY dd 1 31 1 1 1447
1348 (R) AI501 MX DAY mm 1 12 1 1 1448
1349 (R) AI501 MX DAY yy 2000 9999 2000 1 1449
1350 (R) AI501 MN–HI EU –32768 32767 0 0.001 1450
1351 (R) AI501 MN–LO EU –32768 32767 0 0.001 1451
1352 (R) AI501 MN TIM ss 0 5999 0 0.01 1452
1353 (R) AI501 MN TIM mm 0 59 0 1 1453
1354 (R) AI501 MN TIM hh 0 23 0 1 1454
1355 (R) AI501 MN DAY dd 1 31 1 1 1455
1356 (R) AI501 MN DAY mm 1 12 1 1 1456
1357 (R) AI501 MN DAY yy 2000 9999 2000 1 1457
1358 (R) AI502 MX–HI EU –32768 32767 0 0.001 1458
1359 (R) AI502 MX–LO EU –32768 32767 0 0.001 1459
1360 (R) AI502 MX TIM ss 0 5999 0 0.01 1460
1361 (R) AI502 MX TIM mm 0 59 0 1 1461
1362 (R) AI502 MX TIM hh 0 23 0 1 1462
1363 (R) AI502 MX DAY dd 1 31 1 1 1463
1364 (R) AI502 MX DAY mm 1 12 1 1 1464
1365 (R) AI502 MX DAY yy 2000 9999 2000 1 1465
Table E.32 Modbus Register Map
a
(Sheet 33 of 56)
Modbus Register
Address
b
Name/Enums Units Min Max Default
Scale
Facto r
DeviceNet
Parameter
Numbers
