E.59
Date Code 20100129 Instruction Manual SEL-751A Relay
Modbus RTU Communications
Modbus Register Map
1366 (R) AI502 MN–HI EU –32768 32767 0 0.001 1466
1367 (R) AI502 MN–LO EU –32768 32767 0 0.001 1467
1368 (R) AI502 MN TIM ss 0 5999 0 0.01 1468
1369 (R) AI502 MN TIM mm 0 59 0 1 1469
1370 (R) AI502 MN TIM hh 0 23 0 1 1470
1371 (R) AI502 MN DAY dd 1 31 1 1 1471
1372 (R) AI502 MN DAY mm 1 12 1 1 1472
1373 (R) AI502 MN DAY yy 2000 9999 2000 1 1473
1374 (R) AI503 MX–HI EU –32768 32767 0 0.001 1474
1375 (R) AI503 MX–LO EU –32768 32767 0 0.001 1475
1376 (R) AI503 MX TIM ss 0 5999 0 0.01 1476
1377 (R) AI503 MX TIM mm 0 59 0 1 1477
1378 (R) AI503 MX TIM hh 0 23 0 1 1478
1379 (R) AI503 MX DAY dd 1 31 1 1 1479
1380 (R) AI503 MX DAY mm 1 12 1 1 1480
1381 (R) AI503 MX DAY yy 2000 9999 2000 1 1481
1382 (R) AI503 MN–HI EU –32768 32767 0 0.001 1482
1383 (R) AI503 MN–LO EU –32768 32767 0 0.001 1483
1384 (R) AI503 MN TIM ss 0 5999 0 0.01 1484
1385 (R) AI503 MN TIM mm 0 59 0 1 1485
1386 (R) AI503 MN TIM hh 0 23 0 1 1486
1387 (R) AI503 MN DAY dd 1 31 1 1 1487
1388 (R) AI503 MN DAY mm 1 12 1 1 1488
1389 (R) AI503 MN DAY yy 2000 9999 2000 1 1489
1390 (R) AI504 MX–HI EU –32768 32767 0 0.001 1490
1391 (R) AI504 MX–LO EU –32768 32767 0 0.001 1491
1392 (R) AI504 MX TIM ss 0 5999 0 0.01 1492
1393 (R) AI504 MX TIM mm 0 59 0 1 1493
1394 (R) AI504 MX TIM hh 0 23 0 1 1494
1395 (R) AI504 MX DAY dd 1 31 1 1 1495
1396 (R) AI504 MX DAY mm 1 12 1 1 1496
1397 (R) AI504 MX DAY yy 2000 9999 2000 1 1497
1398 (R) AI504 MN–HI EU –32768 32767 0 0.001 1498
1399 (R) AI504 MN–LO EU –32768 32767 0 0.001 1499
1400 (R) AI504 MN TIM ss 0 5999 0 0.01 1500
1401 (R) AI504 MN TIM mm 0 59 0 1 1501
1402 (R) AI504 MN TIM hh 0 23 0 1 1502
1403 (R) AI504 MN DAY dd 1 31 1 1 1503
1404 (R) AI504 MN DAY mm 1 12 1 1 1504
1405 (R) AI504 MN DAY yy 2000 9999 2000 1 1505
Table E.32 Modbus Register Map
a
(Sheet 34 of 56)
Modbus Register
Address
b
Name/Enums Units Min Max Default
Scale
Facto r
DeviceNet
Parameter
Numbers
