E.60
SEL-751A Relay Instruction Manual Date Code 20100129
Modbus RTU Communications
Modbus Register Map
1406 (R) AI505 MX–HI EU –32768 32767 0 0.001 1506
1407 (R) AI505 MX–LO EU –32768 32767 0 0.001 1507
1408 (R) AI505 MX TIM ss 0 5999 0 0.01 1508
1409 (R) AI505 MX TIM mm 0 59 0 1 1509
1410 (R) AI505 MX TIM hh 0 23 0 1 1510
1411 (R) AI505 MX DAY dd 1 31 1 1 1511
1412 (R) AI505 MX DAY mm 1 12 1 1 1512
1413 (R) AI505 MX DAY yy 2000 9999 2000 1 1513
1414 (R) AI505 MN–HI EU –32768 32767 0 0.001 1514
1415 (R) AI505 MN–LO EU –32768 32767 0 0.001 1515
1416 (R) AI505 MN TIM ss 0 5999 0 0.01 1516
1417 (R) AI505 MN TIM mm 0 59 0 1 1517
1418 (R) AI505 MN TIM hh 0 23 0 1 1518
1419 (R) AI505 MN DAY dd 1 31 1 1 1519
1420 (R) AI505 MN DAY mm 1 12 1 1 1520
1421 (R) AI505 MN DAY yy 2000 9999 2000 1 1521
1422 (R) AI506 MX–HI EU –32768 32767 0 0.001 1522
1423 (R) AI506 MX–LO EU –32768 32767 0 0.001 1523
1424 (R) AI506 MX TIM ss 0 5999 0 0.01 1524
1425 (R) AI506 MX TIM mm 0 59 0 1 1525
1426 (R) AI506 MX TIM hh 0 23 0 1 1526
1427 (R) AI506 MX DAY dd 1 31 1 1 1527
1428 (R) AI506 MX DAY mm 1 12 1 1 1528
1429 (R) AI506 MX DAY yy 2000 9999 2000 1 1529
1430 (R) AI506 MN–HI EU –32768 32767 0 0.001 1530
1431 (R) AI506 MN–LO EU –32768 32767 0 0.001 1531
1432 (R) AI506 MN TIM ss 0 5999 0 0.01 1532
1433 (R) AI506 MN TIM mm 0 59 0 1 1533
1434 (R) AI506 MN TIM hh 0 23 0 1 1534
1435 (R) AI506 MN DAY dd 1 31 1 1 1535
1436 (R) AI506 MN DAY mm 1 12 1 1 1536
1437 (R) AI506 MN DAY yy 2000 9999 2000 1 1537
1438 (R) AI507 MX–HI EU –32768 32767 0 0.001 1538
1439 (R) AI507 MX–LO EU –32768 32767 0 0.001 1539
1440 (R) AI507 MX TIM ss 0 5999 0 0.01 1540
1441 (R) AI507 MX TIM mm 0 59 0 1 1541
1442 (R) AI507 MX TIM hh 0 23 0 1 1542
1443 (R) AI507 MX DAY dd 1 31 1 1 1543
1444 (R) AI507 MX DAY mm 1 12 1 1 1544
1445 (R) AI507 MX DAY yy 2000 9999 2000 1 1545
Table E.32 Modbus Register Map
a
(Sheet 35 of 56)
Modbus Register
Address
b
Name/Enums Units Min Max Default
Scale
Facto r
DeviceNet
Parameter
Numbers
