Sel 751A - Page 523

E.61
Date Code 20100129 Instruction Manual SEL-751A Relay
Modbus RTU Communications
Modbus Register Map
1446 (R) AI507 MN–HI EU –32768 32767 0 0.001 1546
1447 (R) AI507 MN–LO EU –32768 32767 0 0.001 1547
1448 (R) AI507 MN TIM ss 0 5999 0 0.01 1548
1449 (R) AI507 MN TIM mm 0 59 0 1 1549
1450 (R) AI507 MN TIM hh 0 23 0 1 1550
1451 (R) AI507 MN DAY dd 1 31 1 1 1551
1452 (R) AI507 MN DAY mm 1 12 1 1 1552
1453 (R) AI507 MN DAY yy 2000 9999 2000 1 1553
1454 (R) AI508 MX–HI EU –32768 32767 0 0.001 1554
1455 (R) AI508 MX–LO EU –32768 32767 0 0.001 1555
1456 (R) AI508 MX TIM ss 0 5999 0 0.01 1556
1457 (R) AI508 MX TIM mm 0 59 0 1 1557
1458 (R) AI508 MX TIM hh 0 23 0 1 1558
1459 (R) AI508 MX DAY dd 1 31 1 1 1559
1460 (R) AI508 MX DAY mm 1 12 1 1 1560
1461 (R) AI508 MX DAY yy 2000 9999 2000 1 1561
1462 (R) AI508 MN–HI EU –32768 32767 0 0.001 1562
1463 (R) AI508 MN–LO EU –32768 32767 0 0.001 1563
1464 (R) AI508 MN TIM ss 0 5999 0 0.01 1564
1465 (R) AI508 MN TIM mm 0 59 0 1 1565
1466 (R) AI508 MN TIM hh 0 23 0 1 1566
1467 (R) AI508 MN DAY dd 1 31 1 1 1567
1468 (R) AI508 MN DAY mm 1 12 1 1 1568
1469 (R) AI508 MN DAY yy 2000 9999 2000 1 1569
MAX/MIN RST Data
1470 (R) MX/MN RST TIM ss 0 5999 0 0.01 1570
1471 (R) MX/MN RST TIM mm 0 59 0 1 1571
1472 (R) MX/MN RST TIM hh 0 23 0 1 1572
1473 (R) MX/MN RST DAT dd 1 31 1 1 1573
1474 (R) MX/MN RST DAT mm 1 12 1 1 1574
1475 (R) MX/MN RST DAT yy 2000 9999 2000 1 1575
1476–1480 (R) Reserved
c
0 0 0 1576–1580
Per Phase Power Data
1481 (R) A REAL POWER kW –32768 32767 0 1 1581
1482 (R) A REACTIVE POWER kVAR –32768 32767 0 1 1582
1483 (R) A APPARENT POWER kVA –32768 32767 0 1 1583
1484 (R) A POWER FACTOR –100 100 0 0.01 1584
1485 (R) B REAL POWER kW –32768 32767 0 1 1585
1486 (R) B REACTIVE POWER kVAR –32768 32767 0 1 1586
1487 (R) B APPARENT POWER kVA –32768 32767 0 1 1587
1488 (R) B POWER FACTOR –100 100 0 0.01 1588
1489 (R) C REAL POWER kW –32768 32767 0 1 1589
1490 (R) C REACTIVE POWER kVAR –32768 32767 0 1 1590
1491 (R) C APPARENT POWER kVA –32768 32767 0 1 1591
1492 (R) C POWER FACTOR -100 100 0 0.01 1592
Table E.32 Modbus Register Map
a
(Sheet 36 of 56)
Modbus Register
Address
b
Name/Enums Units Min Max Default
Scale
Facto r
DeviceNet
Parameter
Numbers
