E.62
SEL-751A Relay Instruction Manual Date Code 20100129
Modbus RTU Communications
Modbus Register Map
Analog Input Data
1493 (R) AI301–HI EU –32768 32767 0 0.001 1593
1494 (R) AI301–LO EU –32768 32767 0 0.001 1594
1495 (R) AI302–HI EU –32768 32767 0 0.001 1595
1496 (R) AI302–LO EU –32768 32767 0 0.001 1596
1497 (R) AI303–HI EU –32768 32767 0 0.001 1597
1498 (R) AI303–LO EU –32768 32767 0 0.001 1598
1499 (R) AI304–HI EU –32768 32767 0 0.001 1599
1500 (R) AI304–LO EU –32768 32767 0 0.001 1600
1501 (R) AI305–HI EU –32768 32767 0 0.001 1601
1502 (R) AI305–LO EU –32768 32767 0 0.001 1602
1503 (R) AI306–HI EU –32768 32767 0 0.001 1603
1504 (R) AI306–LO EU –32768 32767 0 0.001 1604
1505 (R) AI307–HI EU –32768 32767 0 0.001 1605
1506 (R) AI307–LO EU –32768 32767 0 0.001 1606
1507 (R) AI308–HI EU –32768 32767 0 0.001 1607
1508 (R) AI308–LO EU –32768 32767 0 0.001 1608
1509 (R) AI401–HI EU –32768 32767 0 0.001 1609
1510 (R) AI401–LO EU –32768 32767 0 0.001 1610
1511 (R) AI402–HI EU –32768 32767 0 0.001 1611
1512 (R) AI402–LO EU –32768 32767 0 0.001 1612
1513 (R) AI402–HI EU –32768 32767 0 0.001 1613
1514 (R) AI403–LO EU –32768 32767 0 0.001 1614
1515 (R) AI404–HI EU –32768 32767 0 0.001 1615
1516 (R) AI404–LO EU –32768 32767 0 0.001 1616
1517 (R) AI405–HI EU –32768 32767 0 0.001 1617
1518 (R) AI405–LO EU –32768 32767 0 0.001 1618
1519 (R) AI406–HI EU –32768 32767 0 0.001 1619
1520 (R) AI406–LO EU –32768 32767 0 0.001 1620
1521 (R) AI407–HI EU –32768 32767 0 0.001 1621
1522 (R) AI407–LO EU –32768 32767 0 0.001 1622
1523 (R) AI408–HI EU –32768 32767 0 0.001 1623
1524 (R) AI408–LO EU –32768 32767 0 0.001 1624
1525 (R) AI501–HI EU –32768 32767 0 0.001 1625
1526 (R) AI501–LO EU –32768 32767 0 0.001 1626
1527 (R) AI502–HI EU –32768 32767 0 0.001 1627
1528 (R) AI502–LO EU –32768 32767 0 0.001 1628
1529 (R) AI503–HI EU –32768 32767 0 0.001 1629
1530 (R) AI503–LO EU –32768 32767 0 0.001 1630
1531 (R) AI504–HI EU –32768 32767 0 0.001 1631
1532 (R) AI504–LO EU –32768 32767 0 0.001 1632
1533 (R) AI505–HI EU –32768 32767 0 0.001 1633
1534 (R) AI505–LO EU –32768 32767 0 0.001 1634
Table E.32 Modbus Register Map
a
(Sheet 37 of 56)
Modbus Register
Address
b
Name/Enums Units Min Max Default
Scale
Facto r
DeviceNet
Parameter
Numbers
