E.63
Date Code 20100129 Instruction Manual SEL-751A Relay
Modbus RTU Communications
Modbus Register Map
1535 (R) AI506–HI EU –32768 32767 0 0.001 1635
1536 (R) AI506–LO EU –32768 32767 0 0.001 1636
1537 (R) AI507–HI EU –32768 32767 0 0.001 1637
1538 (R) AI507–LO EU –32768 32767 0 0.001 1638
1539 (R) AI508–HI EU –32768 32767 0 0.001 1639
1540 (R) AI508–LO EU –32768 32767 0 0.001 1640
1541–1546 (R) Reserved
c
0 0 0 1641–1646
Math Variables
1547 (R) MV01–HI –32768 32767 0 0.01 1647
1548 (R) MV01–LO –32768 32767 0 0.01 1648
1549 (R) MV02–HI –32768 32767 0 0.01 1649
1550 (R) MV02–LO –32768 32767 0 0.01 1650
1551 (R) MV03–HI –32768 32767 0 0.01 1651
1552 (R) MV03–LO –32768 32767 0 0.01 1652
1553 (R) MV04–HI –32768 32767 0 0.01 1653
1554 (R) MV04–LO –32768 32767 0 0.01 1654
1555 (R) MV05–HI –32768 32767 0 0.01 1655
1556 (R) MV05–LO –32768 32767 0 0.01 1656
1557 (R) MV06–HI –32768 32767 0 0.01 1657
1558 (R) MV06–LO –32768 32767 0 0.01 1658
1559 (R) MV07–HI –32768 32767 0 0.01 1659
1560 (R) MV07–LO –32768 32767 0 0.01 1660
1561 (R) MV08–HI –32768 32767 0 0.01 1661
1562 (R) MV08–LO –32768 32767 0 0.01 1662
1563 (R) MV09–HI –32768 32767 0 0.01 1663
1564 (R) MV09–LO –32768 32767 0 0.01 1664
1565 (R) MV10–HI –32768 32767 0 0.01 1665
1566 (R) MV10–LO –32768 32767 0 0.01 1666
1567 (R) MV11–HI –32768 32767 0 0.01 1667
1568 (R) MV11–LO –32768 32767 0 0.01 1668
1569 (R) MV12–HI –32768 32767 0 0.01 1669
1570 (R) MV12–LO –32768 32767 0 0.01 1670
1571 (R) MV13–HI –32768 32767 0 0.01 1671
1572 (R) MV13–LO –32768 32767 0 0.01 1672
1573 (R) MV14–HI –32768 32767 0 0.01 1673
1574 (R) MV14–LO –32768 32767 0 0.01 1674
1575 (R) MV15–HI –32768 32767 0 0.01 1675
1576 (R) MV15–LO –32768 32767 0 0.01 1676
1577 (R) MV16–HI –32768 32767 0 0.01 1677
1578 (R) MV16–LO –32768 32767 0 0.01 1678
1579 (R) MV17–HI –32768 32767 0 0.01 1679
1580 (R) MV17–LO –32768 32767 0 0.01 1680
1581 (R) MV18–HI –32768 32767 0 0.01 1681
Table E.32 Modbus Register Map
a
(Sheet 38 of 56)
Modbus Register
Address
b
Name/Enums Units Min Max Default
Scale
Facto r
DeviceNet
Parameter
Numbers
