J.14

SEL-751A Relay Instruction Manual Date Code 20100129

Relay Word Bits

Definitions

WARNING Asserts when any of the protection elements (warning level) operates or when the relay detects

self-test failure (see Table 10.7), RTD faults, or DeviceNet communications alarms.

WDGALRM

WDGTRIP

Winding Temperature Alarm and Trip. WDGALRM asserts when any healthy winding RTD tem-

perature exceeds the corresponding alarm set point. WDGTRIP asserts when one or two (when

EWDGV = Y) healthy winding RTD temperatures exceed corresponding trip set points.

Table J.2 Relay Word Bit Definitions for the SEL-751A (Sheet 11 of 11)

Bit Definition Row
