Siemens SCALANCE W1750D UI

Wireless Network Profiles
11.1 Configuring Wireless Network Profiles
SCALANCE W1750D UI
124 Configuration Manual, 02/2018, C79000-G8976-C451-02
2. Based on the security level selected, specify the following parameters.
Parameter Description
Security
Level
Key Management CLick the
Enterprise
security level, select any of the
following options from the
Key management
drop-down
list:
• WPA-2 Enterprise
• WPA Enterprise
• Both (WPA-2 & WPA)
• Dynamic Wired Equivalent Privacy (WEP) with
802.1X—If you do not want to use a session key
from the RADIUS server to derive pairwise unicast
keys, set
Session Key for LEAP
to
Enabled
. This is
required for old printers that use dynamic WEP
through Lightweight Extensible Authentication Proto-
col (LEAP) authentication. The
Session Key for
LEAP
feature is set to
Disabled
by default.
Applicable to
Enter-
prise
and
Personal
security levels only.
For the
Open
security
level, no encryption
settings are required.
For the
Personal
security level, select any of the follow-
ing encryption keys from the
Key management
drop-
down list.
• WPA-2 Personal
• WPA-Personal (Both TKIP and AES Encryption)
• WPA-Personal (TKIP Encryption only) l WPA-
Personal (AES Encryption only) l Both (WPA-2 &
WPA)
• Static WEP
If a WPA-2, WPA encryption, or Both (WPA-2&WPA) is
selected, configure the passphrase:
1.
Select a passphrase format from the
Passphrase
format
drop-down list. The options available are 8–63
alphanumeric characters and 64 hexadecimal chara-
cters.
2.
Enter a passphrase in the
Passphrase
text box and
reconfirm.
NOTE:
The
Passphrase
may contain any
special character except for
".
For
Static WEP
, spe-
cify the following parameters:
3. Select an appropriate value for
WEP key size
from
the WEP key size drop-down list.
You can specify
64-bit or 128-bit .
4.
Select an appropriate value for Tx key from the
Tx
Key
drop-down list. You can specify
1
,
2
,
3
, or
4
.
5. Enter an appropriate
WEP key
and reconfirm.
