Siemens SCALANCE W1750D UI User Manual

AP-VPN Deployment Scenarios
35.3 Scenario 3 - IPsec: Multiple Datacenter Deployment with Primary and Backup Controllers for Redundancy
SCALANCE W1750D UI
Configuration Manual, 02/2018, C79000-G8976-C451-02
545
Configuration Steps
CLI Commands
UI Procedure
6. Configure wired port and wireless
SSIDs using the authentication servers
and access rules; enable authentication
survivability.
Configure wired ports to operate in NAT mode and
associate VLAN 20 to the wired port profile.
(scalance)(config) # wired-port-profile
wired-port (scalance)(wired-port-profile
"wired-port")# switchport-mode access
(scalance)(wired-port-profile "wired-
port")#
allowed-vlan all
(scalance)(wired-port-profile "wired-
port")#
native-vlan 20
(scalance)(wired-port-profile "wired-
port")#
no shutdown
(scalance)(wired-port-profile "wired-
port")#
access-rule-name wired-port
(scalance)(wired-port-profile "wired-
port")#
type employee
(scalance)(wired-port-profile "wired-
port")#
auth- server server1
(scalance)(wired-port-profile "wired-
port")#
auth- server server2
(scalance)(wired-port-profile "wired-
port")#
dot1x (scalance)(wired-port-profile "wired-
port")# exit
(scalance)(config)# enet1-port-profile
wired-port
Configure a wireless SSID to operate in L3 mode for
employee and associate Distributed, L3 mode VLAN
30 to the WLAN SSID profile.
(scalance)(config) # wlan ssid-profile wire-
less- ssid
(scalance)(SSID Profile "wireless-ssid")#
enable
(scalance)(SSID Profile "wireless-ssid")#
type employee
(scalance)(SSID Profile "wireless-ssid")#
essid wireless-ssid
(scalance)(SSID Profile "wireless-ssid")#
opmode wpa2-aes
(scalance)(SSID Profile "wireless-ssid")#
vlan 30
(scalance)(SSID Profile "wireless-ssid")#
auth- server server1
(scalance)(SSID Profile "wireless-ssid")#
auth- server server2
(scalance)(SSID Profile "wireless-ssid")#
auth- survivability
Configure a wireless SSID to operate in L3 mode for
contractor and associate Distributed, L3 mode VLAN
40 to the WLAN SSID profile.
(scalance)(config) # wlan ssid-profile wire-
less- ssid-contractor
(scalance)(SSID Profile "wireless-ssid-
contractor")# enable
(scalance)(SSID Profile "wireless-ssid-
contractor")# type contractor
(scalance)(SSID Profile "wireless-ssid-
contractor")# essid wireless-ssid-
contractor
(scalance)(SSID Profile "wireless-ssid-
contractor")# opmode wpa2-aes
(scalance)(SSID Profile "wireless-ssid-
contractor")# vlan 40
(scalance)(SSID Profile "wireless-ssid-
contractor")# auth-server server1
(scalance)(SSID Profile "wireless-ssid-
contractor")# auth-server server2
(scalance)(SSID Profile "wireless-ssid-
contractor")# auth-survivability
See Configuring a Wired
Profile and Wireless Net-
work Profiles
