AP-VPN Deployment Scenarios
35.4 Scenario 4 - GRE: Single Datacenter Deployment with No Redundancy
SCALANCE W1750D UI
550 Configuration Manual, 02/2018, C79000-G8976-C451-02
Configuration Steps
CLI Commands
UI Procedure
5. Create authentication servers for
user authentication. The example in the
next column assumes 802.1X SSID.
(scalance)(config)# wlan auth-server server1
(scalance)(Auth Server "server1")# ip
10.2.2.1
(scalance)(Auth Server "server1")# port 1812
(scalance)(Auth Server "server1")# acctport
1813
(scalance)(Auth Server "server1")# key
"presharedkey"
(scalance)(Auth Server "server1")# exit
(scalance)(config)# wlan auth-server server2
(scalance)(Auth Server "server1")# ip
10.2.2.2
(scalance)(Auth Server "server1")# port 1812
(scalance)(Auth Server "server1")# acctport
1813
(scalance)(Auth Server "server1")# key
"presharedkey"
See Configuring an
External Server for Au-
thentication
6. Configure wired and wireless SSIDs
using the authentication servers and
access rules; enable authentication
survivability.
Configure wired ports to operate in Centralized, L2
mode and associate VLAN 20 to the wired port pro-
file.
(scalance)(config) # wired-port-profile
wired- port
(scalance)(wired-port-profile "wired-port")#
switchport-mode access
(scalance)(wired-port-profile "wired-port")#
allowed-vlan all
(scalance)(wired-port-profile "wired-port")#
native-vlan 20
(scalance)(wired-port-profile "wired-port")#
no shutdown
(scalance)(wired-port-profile "wired-port")#
access-rule-name wired-port
(scalance)(wired-port-profile "wired-port")#
type employee
(scalance)(wired-port-profile "wired-port")#
auth-server server1
(scalance)(wired-port-profile "wired-port")#
auth-server server2
(scalance)(wired-port-profile "wired-port")#
dot1x
(scalance)(wired-port-profile "wired-port")#
exit
(scalance)(config)# enet1-port-profile
wired-port
Configure a wireless SSID to operate in Centralized,
L2 mode and associate VLAN 20 to the WLAN SSID
profile.
(scalance)(config) # wlan ssid-profile wire-
less- ssid
(scalance)(SSID Profile "wireless-ssid")#
enable
(scalance)(SSID Profile "wireless-ssid")#
type employee
(scalance)(SSID Profile "wireless-ssid")#
essid wireless-ssid
(scalance)(SSID Profile "wireless-ssid")#
opmode wpa2-aes
(scalance)(SSID Profile "wireless-ssid")#
vlan 20
(scalance)(SSID Profile "wireless-ssid")#
auth- server server1
(scalance)(SSID Profile "wireless-ssid")#
auth- server server2
(scalance)(SSID Profile "wireless-ssid")#
auth- survivability
See Configuring a Wired
Profile and Wireless
Network Profiles
