172
Key Setting Operations Using Menus
Chapter 4 Keys
Note
In the emboss function it is not possible to set [Fine Key] on.
• When the edge type is normal, drop border or shadow, enabling the [Fine
Key] function keeps [Key Drop] on.
• When applying a border to the key edge, enabling the [Fine Key]
function halves the border width setting range.
Carrying out a color mix for the key edge fill matte
When you select ‘Matte’ for the edge fill of a border, drop border, or shadow,
you can create a combination of color 1 and color 2 using a wipe pattern
generated by the dedicated pattern generator.
1
In the <Edge Fill> group of the Edge menu, select [Matte], then press
[Matte Adjust].
The edge fill Matte Adjust menu appears.
2
In the <Edge Matte> group, select [Mix Color], turning it on.
3
Adjust the following parameters.
a) The patterns are the same as standard wipes. (For details, see “Wipe Pattern List” in (page
363).)
To select the pattern, display the Mix Pattern Select menu by pressing
[Mix Pattern] in the edge fill Matte Adjust menu. After selecting one of the
4 Bottom Key bottom edge position –2.00 to +2.00
Parameter group [1/2]
Knob Parameter Adjustment Setting values
Parameter group [2/2]
Knob Parameter Adjustment Setting values
1 H Phase Key horizontal position Left edge position
value shown
2 V Phase Key vertical position Top edge position
value shown
Knob Parameter Adjustment Setting values
1 Size Pattern size 0.00 to 100.00
2 Soft Softness of pattern edge 0.00 to 100.00
3 Pattern Pattern number
1 to 24
a)
To Next Page
