173Key Setting Operations Using Menus
Chapter 4 Keys
patterns (standard wipe patterns 1 to 24) displayed in the Mix Pattern
Select menu, you can adjust the following parameters.
4 Adjust color 1 and color 2.
To adjust color 1 press [Color 1], and to adjust color 2 press [Color 2],
turning it on respectively, and adjust the following parameters.
5 If required, set the pattern modifiers.
• When turning [Position] on and setting the pattern position
a) See page 214.
• When turning [Multi] on and replicating the pattern
a) See page 219.
• When turning [Aspect] on and setting the aspect ratio of the pattern
a) See page 218.
Knob Parameter Adjustment Setting values
1 Size Pattern size 0.00 to 100.00
2 Soft Softness of pattern edge 0.00 to 100.00
Knob Parameter Adjustment Setting values
1 Luminance Luminance 0.00 to 100.00
2 Saturation Saturation 0.00 to 100.00
3 Hue Hue 359.99 to 0.00
Knob Parameter Adjustment Setting values
1 Position H Horizontal position
–200.00 to +200.00
a)
2 Position V Vertical position
–200.00 to +200.00
a)
Knob Parameter Adjustment Setting values
1 H Multi Number of repetitions of pattern
horizontally
1 to 63
2 V Multi Number of repetitions of pattern
vertically
1 to 63
3 Invert Type Replication layout
1 to 4
a)
Knob Parameter Adjustment Setting values
1 Aspect Aspect ratio
–100.00 to +100.00
a)
