Sony DVS-9000 System - Page 176

176
Key Setting Operations Using Menus
Chapter 4 Keys
4 Set the mask source parameters.
• When a box is selected
• When a pattern is selected
a) The pattern is the same as a standard wipe. (See “Wipe Pattern List” in Appendix (Volume
1) (page 363).)
To select the pattern, display the Mask Ptn Select menu by pressing the
[Mask Ptn Select] button in the Main Mask menu.
After selecting one of the patterns (standard wipe patterns 1 to 24)
displayed in the Mask Ptn Select menu, you can adjust the following
parameters.
5 To invert the black and white sense of the mask source, press the [Mask
Invert] button, turning it on.
6 When a pattern is selected as the mask source, set the pattern modifiers as
required.
• When turning [Position] on and setting the pattern position
a) See page 214.
Knob Parameter Adjustment Setting values
1 Top Top position –100.00 to +100.00
2 Left Left position –100.00 to +100.00
3 Right Right position –100.00 to +100.00
4 Bottom Bottom position –100.00 to +100.00
5 Soft Box softness 0.00 to 100.00
Knob Parameter Adjustment Setting values
1 Size Pattern size 0.00 to 100.00
2 Soft Edge softness 0.00 to 100.00
5 Pattern Pattern number
1 to 24
a)
Knob Parameter Adjustment Setting values
1 Size Pattern size 0.00 to 100.00
2 Soft Edge softness 0.00 to 100.00
Knob Parameter Adjustment Setting values
1 Position H Horizontal position
–200.00 to +200.00
a)
2 Position V Vertical position
–200.00 to +200.00
a)
